76
Clearing Paper Jams and Skewed Documents
When paper jams and skewed documents are detected during
scanning, the following error codes are displayed in the scanner’s
display panel and scanning is interrupted.
When a paper jam or double feed occurs during scanning, use the
following procedures to clear them.
CAUTION
Be careful when removing jammed paper. take care not to cut your
hand on the edges of the paper.
1
Remove the document.
2
Raise the OPEN lever, and open the upper unit.
Hint
The “C” error code appears in the operating panel when the
upper unit is open..
3
Remove the jammed document.
Paper jam error code
Skew detection error code
