2.2.3 Install a radiator in rear
2.2.2 Install a radiator in top
aa
b
b
1
(C) Install a 240mm radiator in front
Note:
(1) The fans of the radiator should be mounted between top plastic cover and the steel top panel
(2) The radiator thickness can not exceed 38mm
(A) Install a 240mm radiator (B) Install a 280mm radiator
Note: It is recommended that you install the rear radiator
after the M/B is mounted on the M/B tray
2
or
Screw:#6-32*6
