Manual: Coollaboratory Liquid Ultra

To reach maximum cooling and a handling without difficulties, please study the manual of the Liquid

Ultra carefully. You can find a detailed manual at www.coollaboratory.com. The following short-

manual shows the installation on a standard CPU cooler. Please note that the installation of the

Liquid Ultra shall be conducted by manual, because at improper handling the system components

can be damaged. For this purpose Coollaboratory assumes no liability.

Preparation

"Coollaboratory Liquid Ultra" conducts heat better than conventional, previously used heat

conducting pastes. If these pastes have entered the cooler surface's microscopically small

unevenness, they will form an insulating layer between Liquid Ultra and the cooler's surface.

It is extremely important to clean both the CPU and the cooler - even if they are new. Not suitable for

cleaning are scrubbing detergents, oil- or petroleum based detergents or any other substances

leaving remains. It is the best when you use the added cleaning tissue and clean the coolers and

CPU's surfaces carefully. The surfaces must be free of dust and grease. In the case of insufficient

cleaning, contact problems may occur between cooler and CPU. If your cooler is equipped with a

thermal pad, it needs to be removed before using the Liquid Ultra.

Warning: Please note that you can’t use the Coollaboratory Liquid Ultra with a contact area of

aluminum, as it corrodes aluminum. The heatspreader of actual processors consists of nickel-plated

copper, not of aluminum. Advice: The application on copper surfaces is a bit easier than on nickel-

plated ones, but possible is both.

How to apply “Coollaboratory Liquid Ultra”

Add a small drop of Liquid Ultra to your coolers centre. Liquid Ultra only needs to be used sparingly;

the amount of approx. three or four scale line of the syringe is enough. (The exact amount depends

on the size of Heatspreader, on the evenness of the contact areas and the thickness of the gap).

Now spread the Liquid Ultra smoothly across the whole cooling block with the added brush. Do not

use a bare finger to apply Liquid Ultra; the grease will impede its performance. You can apply the

Liquid Ultra on one or both surfaces, but the whole applied amount should not be too big.

"Coollaboratory Liquid Ultra" will cling to the CPU and the cooler's surface by means of adhesion

forces.
