Bevel Detent (fig.9)
The DWE575 and DWE576 are equipped with a
bevel detent feature. As you tilt the base plate you
will hear a click and feel the base plate stop at both
22.5 and 45 degrees. If either of these is the desired
angle, retighten the lever (g) by lowering it. If you
desire another angle, continue tilting the base plate
until the coarse bevel pointer (w) or the fine pointer
(u) aligns with the desired mark.
Cut Length Indicator (fig. 10)
The markings on the side of the base plate show the
length of the slot being cut into the material at the
full depth of the cut. The markings are in increments
of 5mm (1/5").
Mounting and Adjusting the Parallel
Fence (fig. 11)
The parallel fence (x) is used for cutting parallel to
the edge of the workpiece.
MOUNTING
1. Slacken the parallel fence adjustment knob (y)
to allow the parallel fence to pass.
2. Insert the parallel fence (x) in the base plate (i) as
shown.
3. Tighten the parallel fence adjustment knob (y).
ADJUSTING
1. Slacken the fence adjustment knob (y) and set
the parallel fence (x) to the desired width.
The adjustment can be read on the parallel
fence scale.
2. Tighten the fence adjustment knob (y).
Mounting the Dust Extraction Spout
(fig. 1, 6, 12)
Your DWE575/DWE576 circular saw is supplied with
a dust extraction spout.
TO INSTALL DUST EXTRACTION SPOUT
1. Fully loosen depth adjustment lever (q).
2. Place base plate (i) in the lowest position.
3. Align the left half of the dust extraction spout
(gg) over upper blade guard (m) as shown. Be
sure to insert the tab into the casting notch on
the tool. When installed correctly, it will snap fully
over the original depth of cut pointer.
4. Align the right-hand piece with the left.
5. Insert screws and tighten securely.
Guide Rail System (DWE576, fig. 13)
Guide rails, available in different lengths as
accessories, allow the use of the circular saw for
precise, straight clean cuts and simultaneously
protect the workpiece surface against damage.
In conjunction with additional accessories, exact
angled cuts, mitre cuts and fitting work can be
completed with the guide rail system.
Clamps (dd) are available to secure the guide rail (bb)
to the workpiece (fig. 13). Use of these clamps (dd)
ensure that the guide rail (bb) is securely attached to
the workpiece (cc) for safe working. Once the guide
rail is set to the cut line and securely fixed to the
workpiece, there is no movement during cutting.
IMPoRtAnt : The height scale on the unit is set for
using the saw without a guide rail. When using the
saw on the guide rail the difference in height will be
approximately 5.0 mm.
SETTING THE CIRCULAR SAW TO THE GUIDE RAIL
(FIG. 1, 14)
The clearance between the circular saw and the
guide rail (fig. 14, bb) must be very small to achieve
best cutting results. The smaller this clearance the
better the straight line finish will be on the workpiece.
The clearance can be set with the two rail adjusters
(fig. 1, z, aa) for each channel in the base for 0°
cutting (z) and for 1-45° bevel cutting (aa). The
rail adjusters are precision cams that allow for the
reduction of clearance between the unit and guide
rail. Once these adjusters have been set, sideways
movement of the saw during cutting is kept to a
minimum while allowing a smooth cutting action.
notE: The adjusters are set to minimum clearance
in the factory and may need adjusting and setting
before the unit is used. Use the following instructions
for setting the circular saw to the guide rail.
REMEMBER: Set the rail adjusters on the saw to
the guide rail.
1. Undo the screw inside the rail adjuster to allow
for adjustment between the saw and the guide
rail.
2. Retract the lower guard and place the unit
on the guide rail, ensuring the blade is in the
highest position.
3. Rotate the adjuster until saw locks on guide rail.
IMPoRtAnt: Make sure the saw is securely
attached to the rail by trying to push the saw
forward. Ensure there is no movement of the
saw.
4. Rotate the adjuster back slightly until saw slides
easily along the rail.
5. Hold the rail adjuster in position and tighten the
screw again.
