Replacing the display hinges

WARNING: Before working inside your computer, read the

safety information that shipped with your computer and

follow the steps in

Before working inside your computer.

After working inside your computer, follow the instructions

in After working inside your computer. For more safety best

practices, see the Regulatory Compliance home page at

dell.com/regulatory_compliance.

Procedure

1 Align the screw holes on the display hinges with the screw holes on the

display back-cover.

2 Replace the screws that secure the display hinges to the display back-

cover.

Post-requisites

1 Follow the procedure from step 2 to step 5 in “Replacing the display bezel”.

2 Replace the display assembly.

3 Replace the hinge covers.

4 Follow the procedure from step 5 to step 11 in “Replacing the palm rest”.

5 Replace the wireless card.

6 Replace the solid-state drives.

7 Replace the memory modules.

8 Replace the base panel.
