Before you start Operation
Video/audio system connection
Beforeyoustartconnectionofexternal
devices,ensurethatpoweroftheunitis
switchedoff.
Followingoutputsareavailableinthisunit.
Composite video
UsethecablewithyellowplugofanAV
cabletoconnectthecompositevideooutputof
thisunittothevideoinputofaTV/monitor.
Stereo audio
UseapairofAVcables(redforright/white
forleft)toconnectthestereoaudiooutputsof
thisunittotheTVorastereoinputofpower
amplifier.
Coaxial digital audio
Useaspecialcoaxialcabletoconnectthe
coaxialoutputofthisunittothecoaxialinputof
anexternaldevice(e.g.amplifier).
•Theconnectionyoushouldmake
dependsontheTV/monitorinputterminals.
Don’tmakealltheconnectionsatthesametime;
otherwisetheproducedpicturewillbeaffected.
•Thephysicalconnectionshouldaccordto
theaudiooutputsetupofthisunit.
Control elements
Front panel
1 2 3 4 5 6 7 8 9
1.POWERbutton
2.Discslot
3.USBport
4.Display
5.PREVbutton
6.OPEN/CLOSEbutton
7.NEXTbutton
8.PLAY/PAUSEbutton
9.MICjack
Rear panel
1
2
43
1.Powercord
2.Compositevideooutput
3.MixedL/Raudiooutput
4.Coaxialdigitalaudiooutput
Allnecessaryinformationisavailabletocustomersatthesite
www.hyundai-electronics.ru.
