- 6 -
GA-B150M-D2V DDR3 Motherboard Layout
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 GA-B150M-D2V DDR3 motherboard 5 Two SATA cables
5 Motherboard driver disk 5 I/O Shield
5 User's Manual
KB_MS
CPU_FAN
SYS_FAN1
LGA1151
ATX
GA-B150M-D2V DDR3
F_AUDIO
AUDIO
DDR3_1
DDR3_2
BAT
ATX_12V_2X4
Intel
®
B150
R_USB30_1
CODEC
CLR_CMOS
M_BIOS
VGA
USB_LAN
PCIEX16
PCIEX1_1
PCIEX1_2
iTE
®
Super I/O
Realtek
®
GbE LAN
F_USB1F_USB2
F_PANEL
SATA3
5 4
3 2
1 0
DVI
SPDIF_O
COM
F_USB30_1
R_USB30_2
TPM
