1-7 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has been
securely attached to the connector on the motherboard.
1) ATX_12V_2X4
2) ATX
3) CPU_FAN
4) SYS_FAN1/2/3
5) SATA3 0/1/2/3/4/5
6) M.2
7) SATA EXPRESS
8) F_PANEL
9) F_AUDIO
10) SPDIF_O
11) F_USB30_1
12) F_USB1/F_USB2
13) COMA
14) LPT
15) TPM
16) CLR_CMOS
17) BAT
4 1 3
2
11
4
7
16
12
17
6
10
8414
15
139
5
- 12 -
