1-7 Back Panel Connectors

USB 2.0/1.1 Port

TheUSBportsupportstheUSB2.0/1.1specication.UsethisportforUSBdevices.

PS/2 Keyboard/Mouse Port

Use this port to connect a PS/2 mouse or keyboard.

D-Sub Port

The D-Sub port supports a 15-pin D-Sub connector and supports a maximum resolution of 1920x1200@60 Hz

(the actual resolutions supported depend on the monitor being used). Connect a monitor that supports D-Sub

connection to this port.

DVI-D Port

(Note)

TheDVI-DportconformstotheDVI-Dspecicationandsupportsamaximumresolutionof1920x1200@60Hz

(the actual resolutions supported depend on the monitor being used). Connect a monitor that supports DVI-D

connection to this port.

USB Type-C

™

Port

Thereversible USB port supports the USB 3.1 specication and is compatible to the USB 3.0/2.0

specication.UsethisportforUSBdevices.

USB 3.0/2.0 Port

TheUSB3.0portsupportstheUSB3.0specicationandiscompatibletotheUSB2.0/1.1specication.

Use this port for USB devices.

USB 3.1 Port

TheUSB3.1portsupportstheUSB3.1specicationandiscompatibletotheUSB3.0/2.0/1.1specication.

Use this port for USB devices. Use this port for USB devices.

(Note) The DVI-D port does not support D-Sub connection by adapter.

Procedure and driver screen for enabling CrossFire/SLI technology may differ by graphics cards and driver

version.RefertothemanualthatcamewithyourgraphicscardsformoreinformationaboutenablingCrossFire/

SLI technology.

C-2. To Enable SLI Function

After installing the graphics card driver in the operating system, go to the NVIDIA Control Panel. Browse to the

CongureSLI,Surround,Physx screen and ensure Maximize 3D performance is enabled.

- 11 -
