- 5 -
GA-N3150M-D3P/GA-N3050M-D3P Motherboard Layout
The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 GA-N3150M-D3P or GA-N3050M-D3P motherboard
5 Motherboard driver disk 5 Two SATA cables
5 User's Manual 5 I/O Shield
HDMI
CPU_FAN
SYS_FAN
Intel
®
Braswell SoC N3150j
Intel
®
Braswell SoC N3050k
ATX
GA-N3150M-D3P
GA-N3050M-D3P
F_AUDIO
AUDIO
DDR3_1
DDR3_2
BAT
ATX_12V
COMA
KB_MS_USB
CODEC
CLR_CMOS
M_BIOS
VGA
F_USB30
LPT
USB30_LAN
PCI
PCIEX1_1
PCIEX1_2
COMB
iTE
®
Super I/O
Realtek
®
GbE LAN
F_USB1TPM F_USB2 F_PANEL
GL850S
PCIe to PCI
Bridge
SATA3
0 1
j Only for GA-N3150M-D3P.
k Only for GA-N3050M-D3P.
