- 11 -
Hardware Installation
USB Chipset:
- 4xUSB3.0/2.0ports(availablethroughtheinternalUSBheaders)
- 8xUSB2.0/1.1ports(4portsonthebackpanel,4portsavailablethrough
theinternalUSBheaders)
Chipset+Renesas
®
USB 3.0 Hub:
- 3 x USB 3.0/2.0 ports on the back panel
Chipset+Intel
®
USB 3.1 Controller:
- 1 x USB Type-C
™
port on the back panel, with USB 3.1 support
- 1xUSB3.1Type-Aport(red)onthebackpanel
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x PCIe power connector
1 x M.2 Socket 3 connector
1 x SATA Express connector
10 x SATA 6Gb/s connectors
1 x CPU fan header
1xwatercoolingfanheader(CPU_OPT)
3 x system fan headers
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
2 x USB 3.0/2.0 headers
2 x USB 2.0/1.1 headers
1xTrustedPlatformModule(TPM)header
1 x Clear CMOS jumper
Back Panel
Connectors
1 x PS/2 keyboard/mouse port
1 x DisplayPort In port
1 x USB Type-C
™
port, with USB 3.1 support
1xUSB3.1Type-Aport(red)
3 x USB 3.0/2.0 ports
4 x USB 2.0/1.1 ports
1 x RJ-45 port
1 x optical S/PDIF Out connector
5xaudiojacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In,
LineOut,MicIn)
I/O Controller iTE
®
I/O Controller Chip
Hardware
Monitor
System voltage detection
CPU/System/Chipset temperature detection
CPU/CPU OPT/System fan speed detection
CPU/System/Chipset overheating warning
CPU/CPU OPT/System fan fail warning
CPU/CPU OPT/System fan speed control
* Whetherthefanspeedcontrolfunctionissupportedwilldependonthecooleryou
install.
