Conguring a RAID Set
- 66 -
The BIOS Setup menus described in this section may differ from the exact settings for your motherboard.
The actual BIOS Setup menu options you will see shall depend on the motherboard you have and
the BIOS version.
B.ConguringSATAcontrollermodeinBIOSSetup
(The following instructions are based on Intel
®
RapidStorageTechnologyenterprise(Intel
®
RSTe))
MakesuretoconguretheSATAcontrollermodecorrectlyinsystemBIOSSetup.
Step 1:
Turnonyourcomputerandpress<Delete>toenterBIOSSetupduringthePOST(Power-OnSelf-Test).Goto
Peripherals\SATAConguration, make sure SATA Controller(s)isenabled.TocreateRAID,setSATA Mode
Selection to RAID and iRSTe Support to Enabled(Figure1).
Step 2:
IfyouwanttocongureUEFIRAID,followthestepsin"C-1."ToenterthelegacyRAIDROM,savethesettings
andexitBIOSSetup.Referto"C-2"formoreinformation.
Figure 1
