- 5 -

GA-H110M-H DDR3 Motherboard Layout

Box Contents

5 GA-H110M-H DDR3 motherboard

5 Motherboard driver disk 5 Two SATA cables

5 User's Manual 5 I/O Shield

KB_MS

CPU_FAN

SYS_FAN

LGA1151

ATX

GA-H110M-H DDR3

F_AUDIO

AUDIO

DDR3_1

DDR3_2

BAT

ATX_12V

Intel

H110

F_USB30

R_USB30

CODEC

CLR_CMOS

M_BIOS

VGA

HDMI

USB_LAN

PCIEX16

PCIEX1_1

PCIEX1_2

iTE

Super I/O

Realtek

GbE LAN

F_USB1

TPM

F_USB2

F_PANEL

SATA3

1 3

0 2

SPDIF_O

* The box contents above are for reference only and the actual items shall depend on the product package you obtain.

The box contents are subject to change without notice.
