Powerman CA12240/UPS [2/2] Temperature 1 for ups series
![Powerman CA12240/UPS [2/2] Temperature 1 for ups series](/views2/1168259/page2/bg2.png)
CA12240/UPS
■ Constant voltage charge characteristic
■ Cycle service life in relation to depth of discharge
100% D.O.D
100% D.O.D
50% D.O.D
50% D.O.D
30% D.O.D
30% D.O.D
Number of cycles
Capacity (%)
Charge time(hours)
0 2 4 6 8 10 12 14 16 18 20
CHARGED VOLUME
CHARGE VOLTAGE
CHARGE CURRENT
(0.25CA,25℃)
140
120
100
80
60
40
20
0
0.25
0.20
0.15
0.10
0.05
0
15.0
14.0
13.0
12.0
11.0
Charged
(%) (×CA) (V)
Volume
Current
Voltage
The operating environment temperature above 40℃ should be avoided ,After long term storage, The battery actual capacity would
be less than the rated capacity. Full capacity will be obtained through several charge/discharge cycles.
To get the longest life, POWERMAN battery should be fully charged before storage.
■ Temperature effects on capacity ■ Temperature effects float life
Temperature
Capacity (%)
CA: Rated Capacity at 25℃
1
2
3
4
Temperature
1 --- For /UPS series
Life (Years)
■ Self-Discharge Characteristics
■ Relationship of OCV and Residual Capacity % (25℃)
Capacity (%)
Storage Time (Months)
40℃
(104℉)
30℃
(86℉)
20℃
(68℉)
10℃
(50℉)
5℃
(41℉)
0℃
(32℉)
Capacity (25℃)
Residual Capacity (%)
