Confirmation of registered address

To display the addresses of the Lossnay units that are registered with this Lossnay M-NET remote controller.

Each press of in step 2 or 4 displays the address of a registered Lossnay unit and its type, “LC”.

If no Lossnay unit is registered, “ ---” appears in the address display and no type is displayed.

Address deletion

To delete the address of a Lossnay unit registered with this Lossnay M-NET remote controller.

Hold down [ON/OFF] twice for 2 seconds each time in either step 4 or after the registration is completed to delete the regis-

tration of the Lossnay unit that is currently displayed.

FILTER

When the display appears as shown above, hold down [ON/OFF] for 2 seconds each time.

If the registration is deleted correctly, “––” appears in the display.

If the registration is not deleted correctly, “ ” flashes in the display. Check that the select-

ed Lossnay unit addresses and the wiring are correct.

Note:

● In the case of LGH-15 to 100RX

3-E, up to 16 Lossnay units can be registered. In the case of LGH-150/200RX3

-E, up to 8

units can be registered.

● If the registration cannot be completed or deleted correctly, either the set address or the wiring of the Lossnay unit whose

registration you wish to add or delete may be incorrect. Check the wiring and the address that is set.
