Benefits
Managed L2+ Fast
Ethernet Switch
es-3000
series
The Ultimate L2+ Edge Switch for
Triple-play Applications
ł
4GbE Uplink
ł
Backup Power System (BPS) Support
ł
Multi-layer (L2/L3/L4) ACL for Traffic
Prioritization and Security Filtering
ł
IEEE 802.1p with Eight Priority
Queues
ł
WFQ and SPQ Queuing Algorithms
ł
Port Security and enhanced IEEE
802.1x Port Authentication
ł
VLAN Stacking (Q-in-Q)
ł
Telnet, CLI and Web-based
Management
ł
Full Power for simultaneous
operation of 24 PoE Devices
Premium edge switch for service provider and enterprise network
ZyXEL ES-3000 Series L2+ managed Ethernet Switch is designed for service providers and
enterprise networks that demand the most stringent requirement over network resiliency,
QoS and security protection. The ES-3000 Series offers premium features for excellent network
performances and ensures network stability.
Robust and High- Availability System Design
The ES-3000 Series comes with comprehensive features to ensure round-the-clock operation
of the network. With BPS support, power is supplied to the switch in case of an unexpected
power outage. The IEEE802.3ad Link Aggregation feature reduces network downtime by
providing redundant paths and bandwidth aggregation to critical connections. By utilizing
unique design of 4G uplink, you own not only superb transmission bandwidth, but also extra-
secured paths for critical transmission by aggregation of Gigabit ports. IEEE802.1w Rapid
Spanning Tree Protocol (RSTP) allows immediate recovery from failed links by sending packets
via the backup link.
Intelligent QoS for Multi-Service Optimization
Harnessing new cost-cutting IP applications (such as VoIP and video conferencing) in today’s
modern business environment makes a big difference in gaining the market advantage. The
ES-3000 Series provides superior QoS capability to fully utilize the power of applications.
Features like multi-layer (L2/L3/L4) ACL, eight priority queues, DSCP and WFQ scheduling
algorithm allow you to maximize network bandwidth usage and provide quality of network
services. With the support of MVR and IGMP snooping features, the ES-3000 Series enables
successful IP multicasting transmission across multi-VLAN environment. In addition, the ES-
3000 Series supports flexible bandwidth control with granularity of 64kbps which enables
better bandwidth administration for network operators.
