Dear buyer, we thank you for purchase of our product.

Prior to installation and rst use of the electric water heater, please carefully read

these instructions.

THIS APPLIANCE IS NOT INTENDED FOR USE BY PERSONS (INCLUDING CHILDREN)

WITH REDUCED PHYSICAL, SENSORY OR MENTAL CAPABILITIES, OR LACK OF

EXPERIENCE AND KNOWLEDGE, UNLESS THEY HAVE BEEN GIVEN SUPERVISION OR

INSTRUCTION CONCERNING USE OF THE APPLIANCE BY PERSON RESPONSIBLE

FOR THEIR SAFETY.

CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT THEY DO NOT PLAY WITH

THE APPLIANCE.

This water heater has been manufactured in compliance with the relevant standards

and tested by the relevant authorities as indicated by the Safety Certicate and the

Electromagnetic Compatibility Certicate. The technical characteristics of the product are

listed on the label afxed between the inlet and outlet pipes. The installation must be carried

out by qualied staff. All repairs and maintenance work within the water heater, e.g. lime

removal or inspection/replacement of the protective anti-corrosion anode, must be carried

out by the authorised service provider.

BUILDING-IN

The water heater shall be built-in as close as possible to the outlets. When installing the

water heater in a room with bathtub or shower, take into account requirements dened in IEC

Standard 60364-7-701 (VDE 0100, Part 701). It has to be tted to the wall using appropriate

rag bolts with minimum diameter of 8 mm. The wall with feeble charging ability must be

on the spot where the water heater shall be hanged suitably reinforced. Due to universal

construction of the water heater it can be xed vertically on the wall or horizontally on the

wall (output pipes must be on the left).

GBFU 50EDD/V6

GBFU 80 EDD/

GBFU 100 EDD/

GBFU 120 EDD/

GBFU 150 EDD/

A 583 803 948 1103 1318

B 365 565 715 865 1065

C 185 205 200 205 220

D 145 345 495 645 845

Connection and installation dimensions of the water heater [mm]
