Zyxel XGS1910-24 [4/4] Xgs1910 gs1910 series

5-100-01012011 08/12

F o r m o r e p r o d u c t i n f o r m a t i o n , v i s i t u s o n t h e w e b a t w w w. Z y X E L . c o m

ZyXEL Communications Corp. All other brands, product names, or trademarks mentioned are the property of their

respective owners. All specifications are subject to change without notice.

XGS1910/GS1910

Series

24/48-port GbE

Smart Managed Switch

XGS1910/GS1910

Series

24/48-port GbE

Smart Managed Switch

Features

Standard Compliance

• IEEE 802.3

• IEEE 802.3u

• IEEE 802.3ab

• IEEE 802.3z 1000BASE-X

• IEEE 802.3x flow control

• IEEE 802.3az EEE support

• IEEE 802.1p CoS support

• IEEE 802.3af/at (PoE models only)

• Full-duplex and half duplex operation with

IEEE 802.3x flow control and backpressure

• Store and forward

• N-way auto-negotiation

Traffic Management and QoS

• Port-based VLAN

• MAC-based VLAN

• Protocol-based VLAN

• IEEE 802.1Q VLAN tagging

• Guest VLAN

• Voice VLAN

• Storm control (unicast, broadcast, and unknown

traffic) 802.1p priority queues per port

• IEEE 802.1p queuing method (scheduler)

• Input priority mapping

• QoS control list (QCL mode)

• Queue egress shaper

• Tag remarking

• Port-based rate limiting (ingress/egress)

• Rate limiting per IP/TCP/UDP per port

• IEEE 802.3x flow control

• Policy-based prioritization

Class of Service (CoS)

• IEEE 802.1p class of service (SPQ, WFQ, SPQ/WFQ

combination capable)

• DiffServ (DSCP)

• Policy-based CoS

Resilience and Availability

• IEEE 802.1D STP/802.1w RSTP/802.1s MSTP

• IEEE 802.1s instances

• IEEE 802.3ad LACP

(GS1910-24/24HP: max. 12 trunks, 16 links per

trunk; GS1910-48/48HP: max. 26 trunks, 12 links

per trunk; XGS1910-24/48: max. 32 trunks, 12

links per trunk)

• Port error recovery

Security

• IEEE 802.1x

• Port security

• MAC authentication

• MAC address limit

• Layer 2 MAC filtering

• Layer 3 IP filtering

• Layer 4 TCP/UDP socket filtering

• BPDU guard

• Static MAC forwarding

• Multiple RADIUS servers

• Multiple TACACS+ servers

• IEEE 802.1X VLAN and QoS assignment by

RADIUS

• RADIUS authentication

• TACACS+ authentication

• RADIUS accounting

• RADIUS authorization

• TACACS+ authorization

• SSL

• DHCP snooping

• ARP inspection

• UPNP

• Policy-based security filtering

• Port isolation

• IP source guard

• ACL packet filtering

• ACL for policing/port copying

Layer 2 Multicast

• IGMP snooping (v1, v2, v3)

• IGMP snooping fast leave

• IGMP snooping statistics

• IGMP throttling

• MVR support

• IGMP filtering

• IGMP proxy mode & snooping mode selection

• IPv6 MLD snooping

IPv6

• IPv6 management

• IPv6 over Ethernet (RFC 2464)

• Dual-stack (RFC 4213)

• ICMPv6 (RFC 4884)

• Neighbor discovery (RFC 4861)

• IPv6 addressing architecture (RFC 4291)

• SNMP over UDP over IPv4/IPv6

Physical Stacking (XGS1910 Series)

• Single point of management (SPOM)

• Configurable or automatic master re-selection

• Congestion management

• Mixed stacking (up to 8 devices)

• Cross-stack mirroring (many to 1)

• Cross-stack link aggregation

Discovery

• IEEE 802.1AB LLDP

• LLDP-MED

Network Management

• Web-based management

• SNMP v1, v2c, v3

• RMON groups 1, 2, 3, 9 (history, statistics, alarms

and events) for enhanced traffic management,

monitoring and analysis

• Dual-image

• NTPv4 client

• DHCP relay

• DHCP client

• DHCP option 82

• Syslog

• Port mirroring and remote port mirroring

• DNS client, proxy

• sFlow (available on the GS1910 Series and

XGS1910 Series in standalone mode)

• EEE

MIB Information

• RFC 1213 MIB II

• IEEE 802.1Q bridge MIB

• RFC 2819 RMON (group 1, 2, 3, 9)

• RFC 2863 Interface group MIB using SMIv2

• RFC 3411 SNMP management frameworks

• RFC 3414 user-based security model for SNMPv3

• RFC 3415 view-based access control model for

SNMP

• RFC 3635 Ethernet-like MIB

• RFC 3636 IEEE 802.3 MAU MIB

• RFC 4133 entity MIB v3

• RFC 4188 bridge MIB

• RFC 4668 RADIUS auth. client MIB

• RFC 4670 RADIUS accounting MIB

• RFC 5519 multicast group membership

discovery MIB

• IEEE 802.1 MSTP MIB

• IEEE 802.3AB LLDP-MIB

• IEEE 802.3ad LACP MIB

• IEEE 802.1X PAE MIB

• TIA 1057 LLDP-MED

Certifications

• Safety: LVD

• EU RoHS compliant

• EMI: FCC, CE, CNS, ICES

• BSMI: CNS14336 & CNS13438
