Zyxel XGS3700-48 [4/6] Specifications

Zyxel GS3700-24HP [4/6] Specifications
4
XGS3700/GS3700 Series
24/48-port GbE L2+ Switch
Specications
Model XGS3700-24 XGS3700-24HP XGS3700-48 XGS3700-48HP GS3700-24 GS3700-24HP GS3700-48 GS3700-48HP
Product name
24-port GbE
L2+ Switch
with 10GbE
Uplink
24-port GbE
L2+ PoE Switch
with 10GbE
Uplink
48-port GbE
L2+ Switch
with 10GbE
Uplink
48-port GbE
L2+ PoE Switch
with 10GbE
Uplink
24-port GbE
L2+ Switch
24-port GbE
L2+ PoE
Switch
48-port GbE
L2+ Switch
48-port GbE
L2+ PoE
Switch
Switch class
Layer 2 Plus
(Layer 3 Lite)
Layer 2 Plus
(Layer 3 Lite)
Layer 2 Plus
(Layer 3 Lite)
Layer 2 Plus
(Layer 3 Lite)
Layer 2 Plus
(Layer 3 Lite)
Layer 2 Plus
(Layer 3 Lite)
Layer 2 Plus
(Layer 3 Lite)
Layer 2 Plus
(Layer 3 Lite)
Port Density
Total port count 28 28 52 52 28 28 52 52
100/1000 Mbps 24 - 48 - 24 - 48 -
100/1000 Mbps PoE - 24 - 48 - 24 - 48
Gigabit SFP - - - - 4 4 4 4
10-Gigabit SFP+ 4 4 4 4 - - - -
Performance
Switching capacity (Gbps) 128 128 176 176 56 56 104 104
Forwarding rate (Mpps) 95 95 131 131 42 42 77 77
Packet buffer (byte) 2 M 2 M 2 M 2 M 2 M 2 M 2 M 2 M
MAC address table 16 K 16 K 16 K 16 K 16 K 16 K 16 K 16 K
IP address table 1 K 1 K 1 K 1 K 1 K 1 K 1 K 1 K
Routing entries 64 64 64 64 64 64 64 64
Routing domains 128 128 128 128 128 128 128 128
Power
Input 100 - 240 V AC, 50/60 Hz
Max. power consumption
(watt)
44.5 600 66.9 600 38.4 600 58.2 600
Total PoE power budget
(watt)
-
Single PSU
460 W
Dual PSU
1000 W
-
Single PSU
460 W
Dual PSU
1000 W
-
Single PSU
460 W
Dual PSU
1000 W
-
Single PSU
460 W
Dual PSU
1000 W
Redundant power supply Yes (optional) Yes (optional) Yes (optional) Yes (optional) Yes (optional) Yes (optional) Yes (optional) Yes (optional)
Physical Specifications
Dimensions (WxDxH)
(mm/in.)
440 x 437 x 40/17.32 x 17.2 x 1.57
Weight (kg/lb.) 7.27/16.03 7.55/16.64 7.57/16.69 8.02/17.68 7.24/15.96 7.44/16.4 7.55/16.64 8/17.64
Removable power/
fan module
Yes/Yes Yes/Yes Yes/Yes Yes/Yes Yes/Yes Yes/Yes Yes/Yes Yes/Yes
Environmental Specifications
Operating
Temperature 0°C to 50°C/32°F to 122°F
Humidity 10% to 95% (non-condensing)
Storage
Temperature -40°C to 70°C/-40°F to 158°F
Humidity 10% to 90% (non-condensing)
MTBF (hr) 280,000 220,000 250,000 200,000 280,000 220,000 250,000 200,000
Heat dissipation (BTU/hr) 151.745 2046 228.129 2046 130.944 2046 198.462 2046
