3
Vacuum cleaner
Air lter
Vacuum cleaner
(with brush attachment)
Lossnay core
CAUTION
lDo not use the hard nozzle of the vacuum cleaner. It may
damage the exposed surfaces of the Lossnay cores.
lUnder no circumstances should the Lossnay cores be washed in
water.
CAUTION
l Never wash the filters in very hot water and never wash them by
rubbing them.
l Do not dry the filters by exposing them to a flame.
Cleaning the parts
1) Air filters
Use a vacuum cleaner to remove light dust. To remove stubborn
dirt wash in a mild solution of detergent and lukewarm water. (under
40°C)
Maintenance
2) Lossnay cores
Use a vacuum cleaner to suck up the dust and dirt on the exposed
surfaces of the Lossnay cores.
Use a soft brush only to clean exposed surface areas.
Assembly after maintenance
Bearing in mind the following points, assemble the parts following the
sequence for their removal in reverse.
Hinge
Hinge
bracket
Maintenance cover
Maintenance cover
Hinge
Remove all dust and dirt on air filters and Lossnay cores at regular
intervals in order to prevent a deterioration in the Lossnay functions.
Guideline: Clean the air filters once a year.
Clean the Lossnay cores once two year.
(Clean the Lossnay cores once a year If possible.)
(Frequency should be increased depending on the extent of dirt.)
Removing the parts
1) Maintenance cover
1 Pull back the hinged clip. (x3)
2 Open the maintenance cover.
lBe careful not to sandwich the hand.
Air lter
Filter guide
2) Air filters (4 filters)
Remove the air filters, located at the surface of the Lossnay cores, as
below.
Lossnay core
Filters should be set in all side rails of Lossnay cores.
