Zyxel NWA1100-NH [2/4] Application diagram

NWA1100-NH

802.11 b/g/n Long Range PoE Access Point

Application Diagram

Long range coverage

With the boosted 28 dBm output power and 5 dBi high

antenna gain, the ZyXEL NWA1100-NH can amplify signal

transmitted and received for mobile devices with weak

output power to connect to the Wi-Fi networks with ease.

Thanks to this feature, the NWA1100-NH is able to provide

WLAN connectivity to serve most client devices.

Powered device

The ZyXEL NWA1100-NH is designed to be exible in

various deployment scenarios. As a standard powered

device (PD), the NWA1100-NH can work with 802.3af and

802.3at PoE switches to eliminate inconvenience caused

by, for example, insucient power outlets.

Wireless layer-2 isolation

The layer-2 isolation can protect the private network

among client users and allow users to access the shared

devices without entering the rest of private networks for

enhanced security. Also, the intra-BSS blocking prevents

peeping from Wi-Fi clients associated with same AP.

WPA2 enterprise certied

ZyXEL NWA1100-NH has been certied with industrial-

strength WPA2 Enterprise protection and has wide range

support of EAP (Extensible Authentication Protocol)

types. It can be seamlessly integrated with corporate

RADIUS servers.

Feature Highlights

ZyXEL ONE Network utility

To streamline the management process, the ZyXEL

NWA1100-NH comes with ZON utility for administrators

to assign IP addresses of multiple APs through just one

platform. Administrators can save the hassle logging

into each AP to change the default IP addresses before

physical installation.

ZyXELAPCongurator

After deploying a number of APs, repetitive conguration

for the units takes time and eort. The ZyXEL AP

Congurator (ZAC) allows batch AP conguration, backup

and rmware upgrade in three easy steps to signicantly

reduce conguration time and eort.

Access control list

For company without existing RADIUS server,

administrators can utilize the Access Control List (ACL) to

grant or block Wi-Fi access by entering MAC addresses of

the client devices.

GS1920-48HP

48-port GbE Smart

Managed PoE Switch

Servers

Internet

ZON Utility/ZAC

USG1100

Unied Security

Gateway

Floor 2

Room a

Room 1

Room 2

Room 3

Room 4

Room I Room II

Room b Room c

NWA1100-NH

802.11 b/g/n Long Range

PoE Access Point

NWA1100-NH

802.11 b/g/n Long Range

PoE Access Point

NWA1100-NH

802.11 b/g/n Long Range

PoE Access Point

Gigabit

Gigabit PoE

Floor 3

Floor 1

• Assign IP address of multiple APs through ZON utility

• Batch AP conguration, backup and rmware upgrade through ZAC
