Zyxel ZyWALL 1100 [638/829] Authentication method objects

Chapter 35 Object

ZyWALL/USG Series User’s Guide

638

1 Access the Configuration > VPN > IPSec VPN > VPN Gateway > Edit screen.

2 Click Show Advance Setting and select Enable Extended Authentication.

3 Select Server Mode and select an authentication method object from the drop-down list box.

4 Click OK to save the settings.

Figure 428 Example: Using Authentication Method in VPN

35.10.3 Authentication Method Objects

Click Configuration > Object > Auth. Method to display the screen as shown.

Note: You can create up to 16 authentication method objects.

Figure 429 Configuration > Object > Auth. Method

The following table describes the labels in this screen.

Table 280 Configuration > Object > Auth. Method

LABEL DESCRIPTION

Add Click this to create a new entry.

Edit Double-click an entry or select it and click Edit to open a screen where you can modify the

entry’s settings.

Remove To remove an entry, select it and click Remove. The ZyWALL/USG confirms you want to

remove it before doing so.

Object

References

Select an entry and click Object References to open a screen that shows which settings

use the entry.

# This field displays the index number.

Method Name This field displays a descriptive name for identification purposes.

Method List This field displays the authentication method(s) for this entry.
