Zyxel MGS3520-28 [4/6] Specifications
![Zyxel MGS3520-28 [4/6] Specifications](/views2/1169496/page4/bg4.png)
4
MGS3520 Series
24-port/48-port GbE L2 Switch
Specications
Model MGS3520-50 MGS3520-28F MGS3520-28
Product name
44-port FE Fiber L2 Switch 24-port GbE L2 Fiber Switch 24-port GbE L2 Copper Switch
Fan type Fanless Fan-Tray Fanless
Surge protection (6KV) Yes Yes -
CO-LPR (Dying gasp) Yes Yes Yes
Hardware monitor Yes Yes Yes
Port Density
100/1000 GbE BASE-T, fixed 44 - 24
Open SFP (Dual rate: GbE/ FE) 2 24 -
Combo GbE ports (GbE/FE) 4 4 4
Performance
Switching capacity (Gbps) 100 56 56
Forwarding rate (Mpps) 74.4 41.67 41.67
Packet buffer 12 Mbit 12 Mbit 12M bit
MAC address 16 K 16 K 16 K
Power Requirement
AC power model with BPS DC 12 V AC power input (100 V to 240 V); BPS DC power input (11.2 V to 12.8 V)
DC power 48 V model - -36 to -72 V DC -
Physical Specifications
Item
Dimensions (WxDxH)(mm/in.)
440 x 270 x 44/
10.4 x 10.6 x 1.73
440 x 270 x 44/
10.4 x 10.6 x 1.73
440 x 270 x 44/
10.4 x 10.6 x 1.73
Weight (kg/lb.) 3.7/8.16 3.72/8.2 3.09/6.83
Packing
Dimensions (WxDxH)(mm/in.)
512 x 314 x 384/
20.15 x 12.36 x 15.11
512 x 314 x 384/
20.15 x 12.36 x 15.11
500 x 283 x 71/
19.68 x 11.14 x 2.79
Weight (kg/lb.) 4.4/9.7 4.42/9.77 3.636/8.04
Environmental Specifications
Operating
Temperature 0°C to 50°C/32°F to 122°F 0°C to 50°C/32°F to 122°F 0°C to 50°C/32°F to 122°F
Humidity 10% to 95% (Non-condensing) 10% to 95% (Non-condensing) 10% to 95% (Non-condensing)
Storage
Temperature -40°C to 70°C/-40°F to 158°F -40°C to 70°C/-40°F to 158°F -40°C to 70°C/-40°F to 158°F
Humidity 5% to 95% RH (Non-condensing) 5% to 95% RH (Non-condensing) 5% to 95% RH (Non-condensing)
Features
Standard Compliance
• IEEE 802.3 10BASE-T Ethernet
• IEEE 802.3u 100BASE-Tx Ethernet
• IEEE 802.ab 1000BASE-T Ethernet
• IEEE 802.3z 1000BASE-X
• IEEE 802.3x ow control
• IEEE 802.1d spanning tree protocol
• IEEE 802.1w rapid spanning tree protocol
• IEEE 802.1s multiple spanning tree protocol
• IEEE 802.1p class of service, priority protocols
• IEEE 802.1Q VLAN tagging
• IEEE 802.1X port authentication
• IEEE 802.3ad LACP aggregation
• IEEE 802.1ad VLAN stacking
• IEEE 802.3az Energy Ecient Ethernet (EEE)
User Security and Authentication
• IEEE 802.1X authentication
• IP source guard (static IP/MAC binding, DHCP
snooping, ARP inspection)
• IP subnet VLAN & VLAN isolation
• Limiting MAC number per port
• Loop guard prevents a switch from being
aected by another switch which is already in
a looping status
• MAC ltering per port secures access to each
port
• MAC freeze
• Port security, port isolation, port mirroring,
intrusion lock
• RADIUS MAC authentication
• Static MAC forwarding per port: only specied
MAC addresses can access the network (port
security)
• Wire speed ltering per MAC/IP/TCP/UDP
• Wire speed mirroring per MAC/IP/TCP/UDP
• Wire speed rate limiting per MAC/IP/TCP/UDP
• GVRP, automatic VLAN member registration
• Guest VLAN
• CPU protection
• IP-MAC-Port binding
Network Administration Security
• SSH v1/v2
• SSL
• RADIUS accounting
• TACACS+ authentication, accounting
• NTP, daylight saving
