![Zyxel MGS3520-28F [319/356] The following table describes the labels in this screen](/img/pdf.png)
Zyxel MGS3520-28F [319/356] The following table describes the labels in this screen
![Zyxel MGS3520-28F [319/356] The following table describes the labels in this screen](/views2/1169500/page319/bg13f.png)
Chapter 89 Additional Commands
Ethernet Switch CLI Reference Guide
319
This example looks at the current sensor readings from various places in the hardware.The
display for your Switch may be different.
The following table describes the labels in this screen.
sysname# show hardware-monitor C
Customer Part
PSU Serial Number Number & Revision Manufacturing Fan Air Flow
---- ------------- ----------------- ------------ -------------
PSU1 DIYD11M00CN 20110124 front-to-back
PSU2 DIYD11M00DV 20110125 front-to-back
Temperature Unit : (C)
Temperature(%c) Current Max Min Threshold Status
--------------- ------- ----- ----- --------- ------
CPU 45.0 45.0 33.0 80.0 Normal
MAC 47.0 47.0 32.0 90.0 Normal
PHY1 45.0 45.0 31.0 90.0 Normal
PHY2 45.0 45.0 32.0 90.0 Normal
FAN Speed(RPM) Current Max Min Threshold Status
-------------- ------- ----- ---- --------- ------
FAN1 9360 15960 9360 500 Normal
FAN2 9360 16320 9360 500 Normal
FAN3 9360 15720 9360 500 Normal
FAN4 9480 15240 9360 500 Normal
FAN TRAY Air Flow Status
---------- ------------- -------
FAN TRAY 1 front-to-back Present
FAN TRAY 2 front-to-back Present
Voltage(V) Current Max Min Threshold Status
---------- ------- ------ ------ --------- ------
12V_PSU1 11.737 11.918 11.737 +/-10% Normal
12V_PSU2 11.676 11.858 11.676 +/-10% Normal
sysname#
Table 208 show hardware-monitor
LABEL DESCRIPTION
Customer Part This displays information on the fan and power module kits installed in the
Switch.
PSU The PSU (Power Supply Unit) is the power module number.
Serial Number This is a unique number that identifies the inserted power module.
Number & Revision This is the customer part number and revision.
Manufacturing This is the date (yyyy-mm-dd) the module was assembled.
Fan Air Flow This displays the power module fan air flow. All fan air flows within a Switch
must be consistent, that is either front-to-back or back-to-front.
Temperature Unit This field displays the unit of measure for temperatures in this screen.
Temperature This field displays the location of the temperature sensors.
Current This field displays the current temperature at this sensor.
