Benefits

Comprehensive design for various market demand

IES-1000 Series is a pizza box IP-based multi-service access node (MSAN). It has two slots for various

combinations of DSL and VoIP line cards to provide ADSL2+, G.SHDSL and VoIP services to residential

and business customers. It terminates the ATM or EFM traffic of DSL connections and POTS voice

signals to make them IP packets and route them through IP networks. With the highly compact

design (1U heigh), AC and DC power input as well as simple installation, IES-1000 Series can be

deployed at Telco and SMB environment to meet all kinds of market demands.

Robust ADSL2+ solution for Multiple Tenant Unit (MTU) services

With ADSL2+ line card, service providers can offer residential users high-bandwidth Internet access,

on-demand entertainment services and IPTV services on a single network connection. The IES-1000

Series also offers businesses subscribers IP connectivity, VPNs, VLANs, high-quality video conferencing

and legacy service interconnection with bandwidth up to 24 Mbps per port. Moreover, it supports

ATM-based 2-port bonding to provide even higher bandwidth to distant customers. The ADSL2+ line

card is a sophisticated device fully compliant with existing standards and with modern features like

energy-saving, excellent performance and transparent backward to ADSL/ADSL2 compatibility.

Lease line G.SHDSL service for enterprise

With G.SHDSL technology, the IES-1000 Series is applicable for lease line replacement. Using the

TC-PAM modulation technique, IES-1000 Series is compatible with other existing transmission

technologies, allowing service providers to deploy at locations where broadband services already

exist.

M-pair bonding G.SHDSL.bis solution

IES-1000 Series supports the new-generation G.SHDSL.bis line card to provide transmission rate up to

5.7 Mbps symmetrically in a single pair. It also comes with two 100 Mbps Ethernet interfaces toward

Ethernet aggregation network. One IES-1000 Series can accommodate two SAM1316-22 modules to

support 32 SHDSL connections. In addition, the SAM1316-22 supports ITU G.991.2 m-pair bonding in

a physical layer manner. The m-pair bonding can be 2 or 4 pairs and the aggregated payload rate is

around 22.76 Mbps.

VoIP line card to provide media gateway feature

In addition to FAX and modem services, VoIP line card provides a parallel and distributed media

gateway architecture to empower VoIP services by taking advantage of POTS voice signals. With the

architecture, the line card serves up to 24 POTS ports. As part of the benefit, there is no throughput

bottleneck or single-point failure issue in this architecture. The media gateway provides G.711, G.723,

G.726, G.729a/b and T.38 codecs while RFC3261 SIP network signaling protocols is supported.



Multi-service access node, AC or

DC power input with two slide-in

slots for various DSL and VoIP

line card



12-port ADSL/ADSL2/ADSL2+

line card with a splitter built-in

for MTU application



16-port G.SHDSL.bis line card

with m-pair bonding feature for

business applications



24-port VoIP line card with SIP

signaling protocol and MLT

function support



Line card cascading with Fast

Ethernet uplinks



802.1p QoS, priority queuing,

802.1q VLAN tagging and

multicasting support



802.1x authentication,

MAC/Packet filtering and ACL

filtering support



Manageable with the

Windows-based Element

Management System (EMS)

Flexible Provisioning of DSL and

VoIP Services

IES-1000 Series

1U Remote MSAN/DSLAM

with AC/DC Power

IES-1000 Series

1U Remote MSAN/DSLAM

with AC/DC Power
