Smeg CR321A [23/24] Mounting the appliance

Mounting Instructions14

Mounting the Appliance

• Push the appliance for some 38 mm into the kitchen unit and allow at

least 4 mm free space on both sides between the appliance and the

side walls of the kitchen unit (Fig. 1).

• Widely open both the doors and put them together with the door of

the kitchen unit. The procedure is as follows:

− Fix the slide guides (attached in a plastic bag along with the screws

ST 4,2 x 9,5) to the edge of the door. Cover the open holes with the

attached cap.

− Put together the appliance door and the door of the kitchen unit

(Fig. 2).

− Insert the slides into the guides and fix them on the kitchen unit

door some 15 mm from the edge, using the A 4 x 12 screws

(Fig. 3).

− Remove the slide guides and separate the appliance door from the

door of the kitchen unit.

− Fix the slides and be careful not to move them while fixing (Fig. 4).

− Fix the slide guides to the original position.

− Close the door and check the gasket (it should not be creased).

The door should open and close smoothly.

• Fix the appliance into the kitchen unit. On the upper side, fix the three

screws A 4 x 12 through the rail and on the lower side with two

screws A 4 x 16, through the lower hinges. Drill holes, ø 3 x 5

(Fig. 5).

• Seal the gap on the opposite side of the hinge with the enclosed seal

(Fig. 6).

WARNING

Before mounting the appliance into the kitchen unit, disconnect the

power supply and set the thermostat knob to STOP (0) position.
