LSI Logic sas 9212-4i4e hba sgl Инструкция по эксплуатации онлайн [10/10] 156692
![LSI Logic sas 9212-4i4e hba sgl Инструкция по эксплуатации онлайн [10/10] 156692](/views2/1171792/page10/bga.png)
Содержание
- Lsi sas 9212 4i4e pci express to 6gb s serial attached scsi sas host bus adapter hba 1
- Lsi sas 9212 4i4e pci express to 6gb s serial attached scsi sas host bus adapter hba user guide 1
- User guide 1
- Table of contents 3
- Functional descriptions 4
- Hba features 4
- Lsi sas 9212 4i4e pci express to 6gb s sas hba user guide 4
- Overview 4
- Connectors 5
- Lsi sas 9212 4i4e hba characteristics 5
- Operating system support 5
- Pcie connector j1 the lsi sas 9212 4i4e hba supports a x8 interface the pcie connection is through the edge connector j1 which provides connections on both the top j1b and bottom j1a of the board the signal definitions and pin numbers conform to the pcie specification 5
- Sata and sas 5
- Sata sas connectors j5 j6 j7 j8 and j12 the lsi sas 9212 4i4e hba supports sata and sas connections through connector j12 which is an sff 8088 mini sas external right angle connector and connectors j5 j6 j7 and j8 which are sata internal connectors 5
- The following table shows the lsi sas 9212 4i4e hba 5gb s pcie performance 5
- The lsi sas 2008 controller chip contains the sata sas functionality for the lsi sas 9212 4i4e hba the following table shows the lsi sas 9212 4i4e hba 6gb s sas performance 5
- The lsi sas 9212 4i4e hba has onboard flash rom for the firmware and bios the lsi sas 9212 4i4e hba provides one 4 m x 8 bit flash rom for storing the firmware and bios 5
- The lsi sas 9212 4i4e hba supports all major operating systems windows linux red hat linux suse enterprise server sles solaris and vmware refer to http go lsi com hbas for details on the software versions and device driver support for solaris support contact the lsi technical support team 5
- This section describes the different connectors on the lsi sas 9212 4i4e hba see figure 1 for connector locations 5
- Activity led header j11 the lsi sas 9212 4i4e hba has a 4 pin right angle 0 in pitch header for driving external activity leds the 4 pin header connects to two leds which indicate sas activity on port 0 and port 1 6
- J1 pcie x8 lane board edge connector 6
- J4 uart connection 6
- J5 j6 j7 and j8 sas internal connectors 6
- Physical characteristics 6
- The lsi sas 9212 4i4e hba is a 6 in x 2 in low profile board the component height on the top and bottom of the lsi sas 9212 4i4e hba is in accordance with the pcie specification the following figure shows the board connectors 6
- Uart connector j4 the uart connector debug port requires a special cable and lsi support to gather detailed input output controller ioc status 6
- Electrical and environmental specifications 7
- Electrical characteristics 7
- Hardware installation 7
- Safety characteristics 7
- Thermal and atmospheric characteristics 7
- Caution disconnect the computer from the power supply and from any networks before you install the hba or you risk damaging the system 4 replace the mounting bracket system dependent if required for your system replace the full length mounting bracket that ships on the lsi sas 9212 4i4e hba with the shorter bracket supplied save and reuse the two screws that attach the long bracket to attach the short bracket 5 insert the hba in an available pcie slot locate an empty pcie slot remove the blank bracket panel on the back of the computer that aligns with the empty pcie slot save the bracket screw if applicable align the hba to the pcie slot press down gently but firmly to properly seat the hba in the slot the following figure shows how to insert the hba in a pcie slot 8
- Figure 2 installing an lsi pcie to sas x8 hba in a pci express slot 8
- Note the shape size and locations of components on your hba and its bracket might vary from this illustration the lsi sas 9212 4i4e hba requires a x8 pcie slot 6 secure the bracket to the system s chassis install the bracket screw if applicable or engage the system retention mechanism to secure the hba to the system s chassis 8
- Prepare the system turn off the computer and disconnect the power cord from the rear of the power supply 3 remove the cover from the chassis 8
- Revision history 9
- Version 1 july 2011 9
- Version 1 october 2014 9
