LSI SAS 9212-4i4e PCI Express to 6Gb/s SAS HBA User Guide
October 2014
Revision History
7. Connect serial cables between the HBA and any serial HDDs or external enclosures. Figure 2 shows the
locations of the HBA connectors.
8. Replace the cover and any power cords, and power up the system. Replace the system’s cover, reconnect any
power cords, and reconnect any network cables. Turn on the power.
The hardware installation of your LSI SAS 9212-4i4e HBA is complete.
8 Revision History
8.1 Version 1.1, October 2014
Made the following changes:
Updated Operating System Support URL.
Converted the book to the new template.
8.2 Version 1.0, July 2011
Initial release of the document.
