2. Push then slide the hard disk drive and bracket out of the chassis as shown.

3. Push the pins and release the hard disk drive from the bracket.

4. Install the new hard disk drive as follows:

Line up the new hard disk drive with the bracket and secure it with the pins.

5. Slide the hard disk drive and bracket back into position.

6. Slide the computer cover back into position.
