Lenovo b50-30, 59-426187 [41/88] Hard disk drive
![Lenovo b50-30, 59-426189 [41/88] Hard disk drive](/views2/1172275/page41/bg29.png)
Lenovo B50-30/B50-30 Touch/B50-45/B50-70
37
1040 Hard disk drive
Foraccess,removetheseFRUsinorder:
• “1010Batterypack”onpage33
• “1030Bottomslotcover”onpage36
Figure4.Removalstepsofharddiskdrive
Removetwoframefixingscrews .Removetheharddiskdriveinthe
directionbyarrow .
Step Screw (quantity) Color Torque
M2.5x5mm,flat‐head,nylok‐coated(2) Black 2.0~2.5kgf.cm
Attention:
• Do not drop the hard disk drive or apply any physical shock to it.
Theharddiskdriveissensitivetophysicalshock.Improperhandling
cancausedamagesandpermanentlossofdata.
• Beforeremovingthedrive,suggestthecustomertobackupallthe
informationonitifpossible.
• Neverremovethedrivewhilethesystemisoperatingorinsuspend
mode.
a
b
1
1
2
a
