Lenovo thinkcentre s50-30, f0ba003yrk [9/51] Rear view of the computer
![Lenovo thinkcentre s50-30, f0ba003yrk [9/51] Rear view of the computer](/views2/1173121/page9/bg9.png)
4
User Guide
Rear view of the computer
2 3 4 5 6 71
8
8
Security cable slot Power connector
Ethernet connector USB 2.0 connector / USB keyboard
power on connector*
USB 2.0 connectors (2) HDMI-out connector
HDMI-in connector Air vents
* USB keyboard power on: Press Alt + P to power on if the USB keyboard is
connected to this USB port.
