DE-528CT Ethernet Adapter / User‘s Guide

help or quit the Setup and Diagnostics program at any time by

pressing F1 or Esc respectively.

Configuring DE-528CT

Choose Set Up New Configuration from the Main Menu

dialog box, then the Set Up New Configuration Menu appears.

Run Diagnostics

Choose Run Diagnostics from the Main Menu dialog box, then

the Run Diagnostics Menu appears which provides three

testing levels:

♦ EEPROM Test

This test verifies the mode and the register information on the

EEPROM.

♦ On Board Diagnostics

To run this test, choose Run Diagnostics On Board from

the Run Diagnostics Menu dialog box.

This is a series of tests designed to check Network Controller

Registers, on-board RAM, Internal Loopback and Interrupt

Generation.

♦ Network Diagnostics

To run this test, choose Run Diagnostics On Network from

the Run Diagnostics Menu dialog box.

This test verifies that the network cable is connected properly,

sothat the adapter can send and receive data successfully.

4 The On Board Diagnostics test must be run before the Network Diagnostics test is run, in

order to ensure the adapter‘s basic functions are working properly.

2 Configuration and Diagnostics
