![D-Link DFE-550TX [23/29] Cm x 5 cm](/views2/1017353/page23/bg17.png)
D-Link DFE-550TX Adapter
16
Specifications
Network Type:
• Fast Ethernet 100Base-TX
IEEE 802.3u standard for 100Mbps baseband CSMA/CD local area
network
• Ethernet 10BASE-T
IEEE 802.3 standard for 10Mbps baseband CSMA/CD local area network
Jumperless Hardware
NWay Auto-negotiation enabled
Media interface: RJ-45
• Interface controller: D-Link DL10050C
EMI Compatibility:
• FCC Class B
• VCCI Class B
• CE Class B
• C-Tick
• BSMI Class B
Host interface: PCI 2.1/2.2 Bus (Bus Master)
Physical Dimensions:
12.0 cm x 5 cm
Environment:
• Storage: -25° ~ 55°C (-13° ~ 131°F)
• Operating: 0° ~ 50°C (32° ~ 122°F)
• Humidity: 10% to 90% non-condensing
Power Consumption: 1 Watts max
PCB Layer: 2 layers
Software drivers for:
• Microsoft Windows
95OSR2, 95, 98, 98 SE
• Microsoft Windows
2000, ME, XP
• Microsoft NT 3.51, 4.0
• Microsoft Windows for
Workgroups 3.11
• Novell NetWare Server 4.x, 5.x, 6.x
• Novell NetWare Client 32 for DOS
• Novell NetWare Client for DOS
• NDS2 for DOS driver
• FTP PC/TCP
