Levenhuk DTX 720 WiFi

Digital Microscope

Never, under any circumstances, look directly at the Sun,

another bright source of light or at a laser through this device,

as this may cause PERMANENT RETINAL DAMAGE

and may lead to BLINDNESS.

Microscope assembly

Take the microscope and all accessories out of the package. Place the stage on a stable surface. Attach the mount

locking ring (10) to the metal tube of the mount. Insert the metal tube into the opening on the stage and lock it

in place with the ring (10). Insert the microscope into the clamp on the mount arm and tighten the locking screw

(11). Tighten the locking knob (9) to lock the mount arm in place. Place a specimen on the stage and use

the coarse focus knob (8) to focus your view. Use the ﬁne focus knob (6) for maximum precision and sharpness.

Upon focusing your view, tighten the focus locking knob (7) to lock the results.

Using the microscope when connected to PC

Insert the installation CD into your CD drive. The Main Menu window will be displayed. Click the Install Levenhuk

DTX option to install the application and follow the instructions on screen. Connect the microscope to your PC

with a USB cable and run the Levenhuk DTX application. A pop-up message will warn you if the microscope is not

connected to the PC.

Oﬀ/WiFi/USB switch

Brightness adjustment wheel

Power indicator

USB port

LED illumination

Fine focus knob

Focus locking knob

Coarse focus knob

Mount arm locking knob

Mount locking ring

Locking screw

Microscope parts

Capture

an image

Start and stop

video recording

Sequence capture (you can set the time to begin

capturing images or videos, interval between

them, video duration and the number of images

or videos to be captured)

Full screen mode. To exit full screen mode,

press Escape on your keyboard or double-click

anywhere on the screen

The kit includes: microscope, mount, Levenhuk DTX installation CD,

user guide, calibration scale, Li-ion rechargeable battery (built-in),

USB cable, cleaning cloth, adapter.
