JBAT1 Clear CMOS Jumper There is CMOS RAM onboard that is external powered from a battery located on the mainboard to save system configuration data With the CMOS RAM the sys tem can automatically boot into the operating system OS every time it is turned on If you want to clear the system configuration set thejumper to clear the CMOS RAM Keep Data Clear Data IMPORTANT You can clear the CMOS RAM by shorting this jumper while the system is off Afterwards open the jumper Do not clear the CMOS RAM while the system is on because it will damage the mainboard JUSB_PW1 JUSB_PW2 USB pw er Jumpers These jumpers are used to select USB 2 0 ports powered by VCC5 or 5VSB Set to 5VSB if you want the USB 20 ports provide power in standby mode JUSB PW1 for rear USB 2 0 ports JUSB PW2 for on board USB 2 0 connectors Keep USB power to VCC5 Keep USB power to 5VSB IMPORTANT If you set the jumper to 5VSB the power supply must be able to provide at least 2A currents
