Содержание
- Preface 1
- Copyright notice 2
- Preface 2
- Revision history 2
- Trademarks 2
- Preface 3
- Smartphone application 3
- Technical support 3
- Preface 4
- Safety instructions 4
- Ce conformity 5
- Fcc b radio frequency interference statement 5
- Preface 5
- European community compliance statement 6
- Japan vcci class b statement 6
- Korea warning statements 6
- Preface 6
- Radiation exposure statement 6
- Taiwan wireless statements 6
- Battery information 7
- Chemical substances information 7
- Preface 7
- Deutsch 8
- English 8
- Français 8
- Preface 8
- Weee waste electrical and electronic equipment statement 8
- Русский 8
- Español 9
- Nederlands 9
- Polski 9
- Preface 9
- Srpski 9
- Italiano 10
- Magyar 10
- Preface 10
- Türkçe 10
- Česky 10
- Contents 11
- Deutsch de 1 11
- English en 1 11
- Français fr 1 11
- Preface 11
- Installation установка a 1 12
- Preface 12
- Русский ru 1 12
- English 13
- English 14
- Motherboard specifications 14
- English 15
- English 16
- Connectors quick guide 17
- English 17
- Connectors reference guide 18
- English 18
- Back panel quick guide 19
- English 19
- Gaming device port 19
- Important 19
- In order to use usb 3 devices you must connect to a usb 3 port if a usb cable is used it must be usb 3 compliant 19
- Lan port lan port the standard rj 45 lan jack is for connecting to a local area network lan 19
- Mouse keyboard 19
- Mouse keyboard din connector for a ps 19
- Optical s pdif out this s pdif sony philips digital interconnect format connector is provided for digital audio transmission to external speakers through an optical fiber cable 19
- Ps 2 keyboard mouse combo port a combination of ps 19
- Usb 2 port usb 2 port the usb 2 port is for attaching usb 2 devices such as keyboard mouse or other usb 2 compatible devices 19
- Usb 3 port usb 3 port usb 3 port is backward compatible with usb 2 devices it supports data transfer rate up to 5 gbit s superspeed 19
- English 20
- Important 20
- Cpu central processing unit 21
- English 21
- Important 21
- Introduction to the lga 1150 cpu 21
- Cpu heatsink installation 22
- English 22
- Important 22
- Video demonstration 22
- English 23
- English 24
- Important 24
- Dual channel mode population rule 25
- English 25
- Important 25
- Memory 25
- Video demonstration 25
- English 26
- Important 26
- Mounting screw holes 26
- English 27
- Important 27
- Jpwr1 2 atx power connectors 27
- Make sure that all the power cables are securely connected to a proper atx power supply to ensure stable operation of the motherboard 27
- Power supply 27
- These connectors allow you to connect an atx power supply to connect the atx power supply align the power supply cable with the connector and firmly press the cable into the connector if done correctly the clip on the power cable should be hooked on the motherboard s power connector 27
- Video demonstration 27
- Watch the video to learn how to install power supply connectors http youtu be gkdyyr_83i4 27
- English 28
- Expansion slots 28
- Important 28
- Pci1 3 pci slots 28
- Pci_e1 4 pcie expansion slots 28
- English 29
- Single video card installation 29
- Video demonstration 29
- Video graphics cards 29
- English 30
- Important 30
- Internal connectors 30
- Sata1 6 sata connectors 30
- Video demonstration 30
- Cpufan1 2 sysfan1 3 fan power connectors 31
- English 31
- Important 31
- English 32
- Front panel i o connectivity design guide when installing the front panel connectors please use the optional m connector to simplify installation plug all the wires from the computer case into the m connector and then plug the m connector into the motherboard 32
- Important 32
- Jfp1 jfp2 system panel connectors 32
- On the connectors coming from the case pins marked by small triangles are positive wires please use the diagrams above and the writing on the optional m connectors to determine correct connector orientation and placement 32
- The majority of the computer case s front panel connectors will primarily be plugged into jfp1 32
- These connectors connect to the front panel switches and leds the jfp1 connector is compliant with the inte 32
- Video demonstration 32
- Watch the video to learn how to install front panel connectors http youtu be dpelidvnzui 32
- English 33
- Important 33
- Jusb1 2 usb 2 expansion connectors 33
- Jusb3 usb 3 expansion connector 33
- Note that the vcc and gnd pins must be connected correctly to avoid possible damage 33
- The usb 3 port is backwards compatible with usb 2 devices it supports data transfer rates up to 5gbits s superspeed 33
- This connector is designed for connecting high speed usb peripherals such as usb hdds digital cameras mp3 players printers modems and many others 33
- To use a usb 3 device you must connect the device to a usb 3 port through an optional usb 3 compliant cable 33
- Usb0 7 ground 9 no pin 8 ground 6 usb1 4 usb1 33
- After connecting the direct power to this connector please note that you have to enable the direct audio power by adjusting the audio power switch aud_sw1 34
- Audpwr1 direct audio power connector 34
- English 34
- Front panel i o connectivity design guide 34
- Important 34
- Jaud1 front panel audio connector 34
- This connector allows you to connect the front audio panel located on your computer case this connector is compliant with the inte 34
- This connector is used to provide direct power to back panel audio ports the direct audio power can provide the better audio quality please connect this connector with a power supply by an audio power adapter 34
- English 35
- Important 35
- Intel rst only supports pcie m ssd with uefi rom does not support legacy rom 35
- Jlpt1 parallel port connector 35
- M pcie interface does not support raid 0 raid1 raid 5 and raid 10 35
- M2_1 m port optional 35
- The m port supports either m sata 6gb s module or m pcie module 35
- The sata5 and sata6 ports will be unavailable when installing a module in the m port 35
- This connector is used to connect an optional parallel port bracket the parallel port is a standard printer port that supports enhanced parallel port epp and extended capabilities parallel port ecp mode 35
- Cintru 1 ground 36
- English 36
- Ground 36
- Jci1 chassis intrusion connector 36
- Jcom1 serial port connector 36
- Jtpm1 tpm module connector 36
- No pin 36
- Ri 8 cts 6 dsr 4 dtr 36
- This connector connects to a tpm trusted platform module please refer to the tpm security platform manual for more details and usages 36
- This connector connects to the chassis intrusion switch cable if the computer case is opened the chassis intrusion mechanism will be activated the system will record this intrusion and a warning message will flash on screen to clear the warning you must enter the bios utility and clear the record 36
- This connector is a 16550a high speed communication port that sends receives 16 bytes fifos you can attach a serial device 36
- English 37
- Important 37
- Jbat1 clear cmos jumper 37
- Jumpers 37
- Aud_sw1 audio power switch 38
- English 38
- Important 38
- Switch 38
- English 39
- Led status indicators 39
- Led status table 39
- Driver utilities installation 40
- Drivers and utilities 40
- English 40
- Bios setup 41
- English 41
- Entering bios setup 41
- Important 41
- To run boot menu 41
- English 42
- Overview 42
- English 43
- Important 43
- English 44
- Operation 44
- English 45
- Important 45
- Oc menu 45
- English 46
- Important 46
- English 47
- English 48
- English 49
- English 50
- English 51
- English 52
- English 53
- English 54
- Deutsch 55
- Deutsch 56
- Spezifikationen 56
- Deutsch 57
- Deutsch 58
- Anschlussübersicht 59
- Deutsch 59
- Deutsch 60
- Übersicht der motherboard anschlüsse 60
- Deutsch 61
- Lan port lan port die standard rj 45 buchse dient zur verbindung in einem lokalen netzwerk lan 61
- Maus tastatur 61
- Maus tastatur stecker din ist für eine ps 61
- Optischer s pdif ausgang dieser s pdif ausgang sony philips digital interconnect format dient als digitale schnittstelle zur audioausgabe zur den externen lautsprechern durch ein optisches faserkabel 61
- Ps 2 tastatur maus combo anschluss die standard ps 61
- Rücktafel übersicht 61
- Spiele gerät port 61
- Um ein usb 3 einzusetzen schließen sie es bitte mit einem usb 3 kompatiblen kabel an einen usb 3 anschluss an 61
- Usb 2 anschluss usb 2 anschluss der usb 2 anschluss dient zum direkten anschluss von usb 2 geräten wie etwa tastatur maus oder weiterer usb 2 kompatibler geräte 61
- Usb 3 anschluss usb 3 anschluss der usb 3 anschluss ist abwärtskompatibel mit usb 2 geräten er unterstützt datentransferraten bis zu 5 gbit s superspeed 61
- Wichtig 61
- Deutsch 62
- Wichtig 62
- Cpu prozessor 63
- Deutsch 63
- Erklärung zur lga 1150 cpu 63
- Wichtig 63
- Cpu kühlkörper einbau 64
- Deutsch 64
- Video demonstration 64
- Wichtig 64
- Deutsch 65
- Deutsch 66
- Wichtig 66
- Deutsch 67
- Populationsregeln für dual kanal speicher 67
- Speicher 67
- Video demonstration 67
- Wichtig 67
- Deutsch 68
- Schraubenlöcher für die montage 68
- Wichtig 68
- Anhand dieses video an untenstehender adresse erfahren sie wie sie die stromversorgungsstecker installieren http youtu be gkdyyr_83i4 69
- Deutsch 69
- Jpwr1 2 atx stromanschlüsse 69
- Mit diesem anschluss verbinden sie den atx stromanschlusse achten sie bei dem verbinden des atx stromanschlusses darauf dass der anschluss des netzteils richtig auf den anschluss an der hauptplatine ausgerichtet ist drücken sie dann den anschluss des netzteils fest nach unten um eine richtige verbindung zu gewährleisten 69
- Stellen sie sicher dass diese anschlüsse mit den richtigen anschlüssen des netzteils verbunden werden um einen stabilen betrieb der hauptplatine sicherzustellen 69
- Stromversorgung 69
- Video demonstration 69
- Wichtig 69
- Deutsch 70
- Erweiterungssteckplätze 70
- Pci1 3 pci steckplätze 70
- Pci_e1 4 pcie erweiterungssteckplätze 70
- Wichtig 70
- Deutsch 71
- Installation einer grafikkarte 71
- Video demonstration 71
- Video grafikkarten 71
- Deutsch 72
- Interne anschlüsse 72
- Sata1 6 sata anschluüsse 72
- Video demonstration 72
- Wichtig 72
- Cpufan1 2 sysfan1 3 stromanschlüsse für lüfter 73
- Deutsch 73
- Wichtig 73
- An den anschlüssen aus dem gehäuse sind die positiven kabel an den pins die mit kleinen dreiecken markiert sind erkennbar bitte verwenden sie das diagramm oben und die bezeichnungen auf den m connectors um die korrekte positionierung und platzierung festzustellen 74
- Anhand dieses videos an untenstehender adresse erfahren sie wie sie die frontpanel anschlüsse installieren 74
- Deutsch 74
- Die meisten anschlüsse in der frontplatte des pc gehäuse soll vor allem in jfp1 gesteckt werden 74
- Diese anschlüsse sind für das frontpanel angelegt sie dienen zum anschluss der schalter und leds des frontpanels jfp1 erfüllt die anforderungen des inte 74
- Front panel i o connectivity design guide bei der installation des frontpanel anschlüsse nutzen sie bitte die optionalen m connectors um die installation zu vereinfachen schließen sie alle kabel aus dem pc gehäuse zunächst an die m connectors an und stecken sie die m connectors auf das motherboard 74
- Http youtu be dpelidvnzui 74
- Jfp1 jfp2 systemtafelanschlüsse 74
- Video demonstration 74
- Wichtig 74
- Bitte beachten sie dass sie die mit vcc stromführende leitung und gnd erdleitung bezeichneten pins korrekt verbinden müssen ansonsten kann es zu schäden kommen 75
- Der usb 3 anschluss ist abwärtskompatibel mit usb 2 geräten unterstützt datentransferraten bis zu 5 gbit s superspeed 75
- Deutsch 75
- Dieser anschluss eignet sich für die verbindung der hochgeschwindigkeits usb peripheriegeräte wie z b usb festplattenlaufwerke digitalkameras mp3 player drucker modems und ähnliches 75
- Jusb1 2 usb 2 erweiterungsanschluüsse 75
- Jusb3 usb 3 expansion connector 75
- Usb0 7 ground 9 no pin 8 ground 6 usb1 4 usb1 75
- Wichtig 75
- Zur verwendung eines usb 3 gerät müssen sie das gerät an einen usb 3 port über ein optionales usb 3 kompatibles kabel anschließen 75
- Audpwr1 direct audio power anschluss 76
- Deutsch 76
- Jaud1 audioanschluss des frontpanels 76
- Wichtig 76
- Der m port unterstützt entweder ein m sata 6gb s modul oder ein m pcie modul 77
- Deutsch 77
- Die m pcie schnittstelle nicht unterstützt raid 0 raid1 raid 5 und raid 10 77
- Die m pcie schnittstelle unterstützt nur uefi option rom nicht unterstützt legacy option rom 77
- Die parallele schnittstelle ist eine standard druckerschnittstelle die ebenso als enhanced parallel port epp und als extended capabilities parallel port ecp betrieben werden kann 77
- Die sata5 und sata6 anschlüsse werden nicht zur verfügung stehen wenn sie ein modul im m port installieren 77
- Jlpt1 parallele schnittstelle 77
- M2_1 m port optional 77
- Wichtig 77
- Cintru 1 ground 78
- Deutsch 78
- Dieser anschluss wird für das tpm modul trusted platform module ver wendet weitere informationen über den einsatz des optionalen tpm modules entnehmen sie bitte dem tpm plattform handbuch 78
- Dieser anschluss wird mit einem kontaktschalter verbunden wenn das pc gehäuse geöffnet wird aktiviert dies den gehäuse kontaktschalter und eine warnmeldung wird auf dem bildschirm angezeigt um die warnmeldung zu löschen muss das bios aufgerufen und die aufzeichnung gelöscht werden 78
- Es handelt sich um eine 16550a kommunikationsschnittstelle die 16 bytes fifos sendet empfängt hier lässt sich eine serielle maus oder andere serielle geräte direkt anschließen 78
- Ground 78
- Jci1 gehäusekontaktanschluss 78
- Jcom1 serieller anschluss 78
- Jtpm1 tpm anschluss 78
- No pin 78
- Ri 8 cts 6 dsr 4 dtr 78
- Deutsch 79
- Jbat1 steckbrücke zur cmos löschung 79
- Steckbrücken 79
- Wichtig 79
- Aud_sw1 audio power schalter 80
- Deutsch 80
- Schalter 80
- Wichtig 80
- Deutsch 81
- Die tabelle der led statusanzeigen 81
- Led statusanzeige 81
- Deutsch 82
- Treiber dienstprogramme installer 82
- Treiber und dienstprogramme 82
- Aufruf des bios setups 83
- Bios setup 83
- Deutsch 83
- To run boot menu 83
- Wichtig 83
- Deutsch 84
- Überbilck 84
- Deutsch 85
- Wichtig 85
- Betrieb 86
- Deutsch 86
- Deutsch 87
- Oc menü 87
- Wichtig 87
- Deutsch 88
- Wichtig 88
- Deutsch 89
- Deutsch 90
- Deutsch 91
- Deutsch 92
- Deutsch 93
- Deutsch 94
- Deutsch 95
- Deutsch 96
- Français 97
- Français 98
- Spécifications 98
- Français 99
- Français 100
- Français 101
- Guide rapide des connecteurs 101
- Français 102
- Guide référence des connecteurs 102
- Français 103
- Guide rapide du panneau arrière 103
- Important 103
- Port lan port lan la prise standard rj 45 lan sert à la connexion au réseau local local area network lan 103
- Port ps 2 combo clavier souris combinaison d un connecteur souris clavier din ps 2 pour une souris ou un clavier ps 103
- Port usb 2 port usb 2 le port usb 2 sert à brancher des périphériques usb 2 tels que le clavier la souris ou d autres périphériques compatibles usb 2 103
- Port usb 3 port usb 3 le port usb 3 est rétro compatible avec les périphériques usb 2 il supporte un taux de transfert jusqu à 5 gbit s super vitesse 103
- Ports pour périphérique de jeux 103
- S pdif out optique ce connecteur s pdif sony et philips digital interconnect format est utilisé pour la transmission audio numérique à des haut parleurs externes via un câble optique 103
- Si vous voulez installer un périphérique usb 3 vous devez vous connecter à un port usb 3 si un câble usb est utilisé il doit être compatible usb 3 103
- Français 104
- Important 104
- Français 105
- Important 105
- Introduction du lga 1150 cpu 105
- Processeur cpu 105
- Démonstration de vidéo 106
- Français 106
- Important 106
- Installation du cpu et son ventilateur 106
- Français 107
- Français 108
- Important 108
- Démonstration de vidéo 109
- Français 109
- Important 109
- Mémoire 109
- Règle de population en mode double canal 109
- Français 110
- Important 110
- Trous taraudés de montage 110
- Ce connecteur vous permet de relier une alimentation atx pour cela alignez le câble d alimentation avec le connecteur et appuyez fermement le câble dans le connecteur si ceci est bien fait la pince sur le câble d alimentation doit être accrochée sur le connecteur d alimentation de la carte mère 111
- Connecteurs d alimentation 111
- Démonstration de vidéo 111
- Français 111
- Http youtu be gkdyyr_83i4 111
- Important 111
- Jpwr1 2 connecteur d alimentation atx 111
- Veuillez vous assurer que tous les connecteurs sont connectés aux bonnes alimentations atx afin garantir une opération stable de la carte mère 111
- Emplacements d extension 112
- Français 112
- Important 112
- Pci1 3 emplacement pci 112
- Pci_e1 4 emplacement d extension pcie 112
- Cartes vidéo graphiques 113
- Démonstration de vidéo 113
- Français 113
- Installation de simple carte vidéo 113
- Connecteurs internes 114
- Démonstration de vidéo 114
- Français 114
- Important 114
- Sata1 6 connecteurs sata 114
- Cpufan1 2 sysfan1 3 connecteur d alimentation du ventilateur 115
- Français 115
- Important 115
- Ces connecteurs se connectent aux interrupteurs et leds du panneau avant le jfp1 est conforme au guide de conception de la connectivité entrée sortie du panneau avant inte 116
- Démonstration de vidéo 116
- Français 116
- Important 116
- Jfp1 jfp2 connecteur panneau système 116
- La majorité des connecteurs sur le panneau avant du boîtier d ordinateur sont connectés au jfp1 à l origine 116
- Lors de l installation des connecteurs du panneau avant veuillez utiliser le m connector en option afin de vous simplifier l installation connectez tous les fils du boîtier à m connector et puis connectez le m connector à la carte mère 116
- Sur les branchements du boîtiers les broches marquées par de petits triangles sont des fils positifs veuillez utiliser les diagrammes ci dessus et l explication relative au m connector en option pour déterminer la bonne orientation et la position des connecteurs 116
- Voir le vidéo pour l installation des connecteurs du panneau avant http youtu be dpelidvnzui 116
- Ce connecteur est destiné à connecter les périphériques usb haute vitesse tels que les disques durs usb les appareils photo numériques les lecteurs mp3 les imprimantes les modems et les appareils similaires 117
- Français 117
- Important 117
- Jusb1 2 connecteurs d extension usb 2 117
- Jusb3 connecteurs d extension usb 3 117
- Le port usb 3 est rétro compatible avec les périphériques usb 2 il supporte un taux de transfert jusqu à 5 gbit s super vitesse 117
- Notez que les pins de vcc et gnd doivent être branchées correctement afin d éviter tout dommage possible 117
- Notez que les pins vcc et gnd doivent être branchées correctement afin d éviter tout dommage possible 117
- Si vous voulez utiliser un périphérique usb 3 il faut utiliser une câble usb 3 117
- Usb0 7 ground 9 no pin 8 ground 6 usb1 4 usb1 117
- Audpwr1 connecteur direct audio power 118
- Français 118
- Important 118
- Jaud1 connecteur audio panneau avant 118
- Ce connecteur sert à connecter un support de port parallèle optionnel le port parallèle est un port d imprimante standard qui supporte les modes enhanced parallel port epp et extended capabilities parallel port ecp 119
- Français 119
- Important 119
- Jlpt1 connecteur de port parallèle 119
- L intreface m pcie ne supporte pas raid 0 raid1 raid 5 et raid 10 119
- L intreface m pcie ne supporte que uefi option rom mais pas legacy option rom 119
- Le port m supporte soit le module m sata 6gb s ou celui m pcie 119
- Les ports sata5 et sata6 deviennent indisponibles lorsqu un module est installé dans le port m 119
- M2_1 port m en option 119
- Ce connecteur est relié à un câble d interrupteur intrusion châssis si le châssis est ouvert l interrupteur en informera le système qui enregistera ce statut et affichera un écran d alerte pour effacer ce message d alerte vous devez entrer dans le bios et désactiver l alerte 120
- Ce connecteur est relié à un module tpm trusted platform module en option veuillez vous référer au manuel du module tpm pour plus d information détaillée 120
- Cintru 1 ground 120
- Français 120
- Ground 120
- Jci1 connecteur intrusion châssis 120
- Jcom1 connecteur de port sérial 120
- Jtpm1 connecteur de module tpm 120
- Le port serial est un port de communications de haute vitesse de 16550a qui envoie reçoit 16 bytes fifos vous pouvez attacher un périphérique sérail 120
- No pin 120
- Ri 8 cts 6 dsr 4 dtr 120
- Cavaliers 121
- Français 121
- Important 121
- Jbat1 cavalier d effacement cmos 121
- Aud_sw1 interrupteur audio power 122
- Français 122
- Important 122
- Interrupteur 122
- Français 123
- Indicateurs d état led 123
- Tableau d état led 123
- Français 124
- Installation de pilotes utilitaires 124
- Pilotes et utilitaires 124
- Configuration bios 125
- Entrer dans le réglage bios 125
- Français 125
- Important 125
- To run boot menu 125
- Français 126
- Vue d ensemble 126
- Français 127
- Important 127
- Français 128
- Opération 128
- Français 129
- Important 129
- Oc menu 129
- Français 130
- Important 130
- Français 131
- Français 132
- Français 133
- Français 134
- Français 135
- Français 136
- Français 137
- Français 138
- Русский 139
- Русский 140
- Характеристики материнской платы 140
- Русский 141
- Русский 142
- Русский 143
- Краткое руководство по разъемам 144
- Русский 144
- Русский 145
- Справочное руководство по разъемам 145
- Iдля использования устройств usb 3 их следует подключать к порту usb 3 используемый usb кабель должен быть совместим со стандартом usb 3 146
- Внимание 146
- Для подключения мыши клавиатуры с интерфейсом ps 146
- Комбинированные порты ps 2 клавиатуры мыши комбинированный разъем din ps 146
- Краткое руководство по работе с задней панелью 146
- Оптический выход s pdif разъем s pdif цифровой интерфейс sony philips предназначен для передачи цифрового аудио на внешние громкоговорители через оптоволоконный кабель 146
- Порт lan порт lan стандартный разъем rj 45 для подключения к локальной вычислительной сети lan 146
- Порт usb 2 порт usb 2 порт usb 2 предназначен для подключения usb 2 устройств таких как клавиатура мышь и другие usb 2 совместимые устройства 146
- Порт usb 3 порт usb 3 порт usb 3 обратно совместим с устройствами usb 2 поддержка передачи данных со скоростью до 5 гбит с superspeed 146
- Порт игрового устройства 146
- Русский 146
- Внимание 147
- Русский 147
- Внимание 148
- Процессор lga 1150 148
- Русский 148
- Цп центральный процессор 148
- Видео демонстрация 149
- Внимание 149
- Русский 149
- Установка цп и радиатора 149
- Русский 150
- Внимание 151
- Русский 151
- Видео демонстрация 152
- Внимание 152
- Память 152
- Правила заполнения гнезд при использовании двухканального режима dual channel 152
- Русский 152
- Внимание 153
- Отверстия под установочные винты 153
- Русский 153
- Jpwr1 2 разъемы питания atx 154
- Видео демонстрация 154
- Внимание 154
- Для обеспечения стабильной работы системной платы проверьте надежность подключения всех кабелей питания к соответствующему блоку питания атх 154
- Русский 154
- Смотрите видео чтобы узнать как установить разъем питания http youtu be gkdyyr_83i4 154
- Электропитание 154
- Эти разъемы предназначены для подключения разъема питания atx для подключения atx разъема питания совместите кабель питания с разъемом и прочно закрепите его при правильном выполнении подключения защелка на кабеле питания закрепляется в силовом разъеме материнской платы 154
- Pci1 3 слоты pci 155
- Pci_e1 4 слоты расширения pcie 155
- Внимание 155
- Русский 155
- Слоты расширения 155
- Видео демонстрация 156
- Видео установка дискретной видеокарты 156
- Русский 156
- Установка одной видеокарты 156
- Sata1 6 разъемы sata 157
- Видео демонстрация 157
- Внимание 157
- Внутренние разъемы 157
- Русский 157
- Cpufan1 2 sysfan1 3 разъемы питания вентиляторов 158
- Внимание 158
- Русский 158
- Front panel i o connectivity design при установке разъемов передней панели для удобства используются переходники и кабели входящие в комплект поставки подключите все провода системного блока к разъемам а затем подключите разъемы к материнской плате 159
- Jfp1 jfp2 разъемы панели системы 159
- Видео демонстрация 159
- Внимание 159
- На разъемах выходящих из системного блока плюсовым проводам соответствуют контакты обозначенные небольшими треугольниками для определения правильности направления и расположения служат вышеуказанные схемы и надписи на дополнительных разъемах большинство кнопок расположенных на передней панели системного блока подключены к разъему jfp1 159
- Русский 159
- Смотрите видео чтобы узнать как подключить разъемы передней панели http youtu be dpelidvnzui 159
- Эти разъемы служат для подключения кнопок и светодиодных индикаторов расположенных на передней панели разъем jfp1 соответствует стандартам inte 159
- Jusb1 2 разъемы расширения usb 2 160
- Jusb3 разъем расширения usb 3 160
- Usb0 7 ground 9 no pin 8 ground 6 usb1 4 usb1 160
- Внимание 160
- Для использования устройства usb 3 подключитесь к разъему usb 3 с помощью кабеля usb 3 приобретается дополнительно 160
- Помните что во избежание повреждений необходимо правильно подключать контакты vcc и gnd 160
- Порт usb 3 обратно совместим с устройствами usb 2 он поддерживает скорость передачи данных до 5 гбит с superspeed 160
- Русский 160
- Этот разъем служит для подключения таких высокоскоростных периферийных устройств как жесткие диски с интерфейсом usb цифровые камеры мрз плееры принтеры модемы и т д 160
- Audpwr1 коннектор прямого питания audio 161
- Jaud1 аудиоразъем на передней панели 161
- Внимание 161
- Русский 161
- Intel rst поддерживает pcie m ssd только с uefi rom при наличии legacy rom поддержка невозможна 162
- Jlpt1 разъем параллельного порта 162
- M2_1 порт m опционально 162
- Внимание 162
- Интерфейс m pcie не поддерживает raid 0 raid1 raid 5 и raid 10 162
- Порт m поддерживает как модули m sata 6гб с так и модули m pcie 162
- Порты sata5 и sata6 будут недоступны при установке модуля в порт m 162
- Русский 162
- Этот коннектор используется для подключения опциональной планки параллельного порта параллельный порт это стандартный порт для принтера он поддерживает режимы epp усовершенствованный параллельный порт и ecp параллельный порт с дополнительными возможностями 162
- Cintru 1 ground 163
- Ground 163
- Jci1 разъем датчика открытия корпуса 163
- Jcom1 разъем последовательного порта 163
- Jtpm1 разъем модуля трм 163
- No pin 163
- Ri 8 cts 6 dsr 4 dtr 163
- Данный разъем подключается к модулю трм trusted platform module дополнительные сведения см в описании модуля безопасности трм 163
- Данный разъем является высокоскоростным последовательным портом передачи данных 16550а с 16 разрядной передачей fifo к этому разъему можно подключить устройство c последовательным интерфейсом 163
- К этому разъему подключается кабель датчика установленного в корпусе этот датчик срабатывает при вскрытии системного блока система запоминает это событие и выдает предупреждение на экран для отключения предупреждения необходимо удалить записанное событие в настройках bios 163
- Русский 163
- Jbat1 джампер очистки данных cmos 164
- Внимание 164
- Джампер 164
- Русский 164
- Aud_sw1 переключатель питания audio 165
- Внимание 165
- Переключатель 165
- Русский 165
- Русский 166
- Световые индикаторы 166
- Таблица состояния индикатора 166
- Драйверы и утилиты 167
- Русский 167
- Установка драйверы и утилит 167
- To run boot menu 168
- Внимание 168
- Вход в настройки bios 168
- Для запуска в меню загрузки 168
- Нажмите на клавишу del для запуска в меню настройки или f11 168
- Настройка bios 168
- Русский 168
- Общие сведения 169
- Русский 169
- Внимание 170
- Русский 170
- Работа 171
- Русский 171
- Внимание 172
- Меню oc 172
- Русский 172
- Внимание 173
- Русский 173
- Русский 174
- Русский 175
- Русский 176
- Русский 177
- Русский 178
- Русский 179
- Русский 180
- Русский 181
- Русский 182
- Installation установка 183
- Installation установка 184
- Installation установка 185
- Installation установка 186
- Memory speicher mémoire памяти 186
- Connecteurs d alimentation pазъема питания 189
- Http youtu be gkdyyr_83i4 189
- Installation установка 189
- Power connector atx stromanshcluss 189
- Или 189
- Installation установка 190
- Http youtu be rzsmpqxythc 191
- Installation установка 191
- Sata hdd 191
- Или 191
- Installation установка 192
- Connecteur panneau avant pазъемов передней панели 193
- Front panel connector frontpanel anschluss 193
- Hd_led hd_led rst_sw rst_sw rsvd_dnu 193
- Http youtu be dpelidvnzui 193
- Installation установка 193
- Connecteur périphérique периферийных разъемов 194
- Installation установка 194
- Peripheral connector peripheriestecker 194
- Или 194
- Installation установка 196
Похожие устройства
- MSI z97 gaming 3 Инструкция по эксплуатации
- MSI z97 gaming 5 Инструкция по эксплуатации
- MSI h97i ac Инструкция по эксплуатации
- MSI z97-g43 Инструкция по эксплуатации
- МАССА-К ВЭМ-150.2-А1 Инструкция по эксплуатации
- МАССА-К ВЭМ-150.2-А2 Инструкция по эксплуатации
- МАССА-К ВЭМ-150.2-А3 Инструкция по эксплуатации
- МАССА-К В1-15-«САША» Инструкция по эксплуатации
- МАССА-К RA Инструкция по эксплуатации
- МАССА-К RC Инструкция по эксплуатации
- МАССА-К RP Инструкция по эксплуатации
- МАССА-К R2P Инструкция по эксплуатации
- МАССА-К A01/ТВ Инструкция по эксплуатации
- МАССА-К P/ТВ Инструкция по эксплуатации
- МАССА-К P/ТВ Инструкция по эксплуатации
- МАССА-К A/4D Инструкция по эксплуатации
- МАССА-К AB/4D Инструкция по эксплуатации
- МАССА-К A.W/4D Инструкция по эксплуатации
- МАССА-К AB.W/4D Инструкция по эксплуатации
- Homedics BMSC-1000H-EU Инструкция по эксплуатации
