MSI z170a-g43 plus Инструкция по эксплуатации онлайн
1
Unpacking
Unpacking
Thank you for buying the MSI
®
motherboard Z170A-G43 PLUS/ H170A-G43 PLUS/
Z170A-G43 PLUS AC/ H170A-G43 PLUS AC. Check to make sure your motherboard
box contains the following items. If something is missing, contact your dealer as soon
as possible.
SATA Cable x6
Drivers & Utilities
Disc
Motherboard User
Guide
I/O Shield
Motherboard
Antenna x2
For Z170A-G43 PLUS AC/ H170A-G43 PLUS AC
Intel 8260
Wi-Fi/
Bluetooth
Module
Wi-Fi/ Bluetooth
Module Bracket
Antenna Bracket
Intel 8260 Wi-Fi/
Bluetooth Driver
Disc
