Overview of Components
Component Contents
Port Name Port Type Page
CPUFAN1,SYSFAN1~2 Fan Connectors 29
CPU Socket LGA1151 CPU Socket 23
DIMM1~4 DIMM Slots 24
EZ Debug LED Debug LED indicators 31
JAUD1 Front Audio Connector 28
JBAT1 Clear CMOS (Reset BIOS) Jumper 30
JCI1 Chassis Intrusion Connector 31
JCOM1 Serial Port Connector 28
JFP1, JFP2 Front Panel Connectors 26
JLPT1 Parallel Port Connector 30
JPWR1~2 Power Connectors 26
JTPM1 TPM Module Connector 28
JUSB1 USB 3.1 Gen1 Connector 27
JUSB2~3 USB 2.0 Connectors 27
PCI_E1~3 PCIe Expansion Slots 25
SATA1~6 SATA 6Gb/s Connectors 25
SE1_21 SATAe Connector 25
