16
Specications
Continued from previous page
USB
● ASMedia
®
ASM1142 Chipset
▶ 1x USB 3.1 Gen2 Type-C port on the back panel
● Intel
®
Z170 Chipset
▶ 6x USB 3.1 Gen1 (SuperSpeed USB) ports (2 ports on
the back panel, 4 ports available through the internal
USB connector)
▶ 6x USB 2.0 (High-speed USB) ports (2 ports on the
back panel, 4 ports available through the internal USB
connector)
Audio
● Realtek
®
ALC1150 Codec
● 7.1-Channel High Definition Audio
LAN 1x Intel
®
I219-V Gigabit LAN controller
Back Panel
Connectors
● 1x PS/2 mouse port
● 1x PS/2 keyboard port
● 1x VGA port
● 1x DVI-D port
● 1x USB 3.1 Gen2 Type-C port
● 2x USB 3.1 Gen1 ports
● 1x HDMI
™
port
● 1x LAN (RJ45) port
● 2x USB 2.0 ports
● 6x audio jacks
Continued on next page
