Overview of Components
Component Contents
Port Name Port Type Page
CPUFAN1~2, SYSFAN1~3 Fan Connectors 36
CPU Socket LGA1151 CPU Socket 26
DIMM1~4 DIMM Slots 27
EZ Debug LED Debug LED indicators 37
JAUD1 Front Audio Connector 29
JBAT1 Clear CMOS (Reset BIOS) Jumper 37
JCI1 Chassis Intrusion Connector 34
JCOM1 Serial Port Connector 35
JFP1, JFP2 Front Panel Connectors 33
JLPT1 Parallel Port Connector 35
JPWR1~2 Power Connectors 31
JTPM1 TPM Module Connector 33
JUSB1~2 USB 2.0 Connectors 32
JUSB3~4 USB 3.1 Gen1 Connectors 32
M2_1 M.2 Slots 30
PCI_E1~6 PCIe Expansion Slots 28
SATA1~6 SATA 6Gb/s Connectors 29
