Makita hw121 [11/16] En ec declaration of conformity
Makita Corporation - Japan
MODEL SERIAL NUMBER
EN EC Declaration of conformity
We Makita Corporation, Anjo, Aichi, Japan declare that the following Makita Machine(s):
Designation of Machine High Pressure Washer
Model No / Type HW121
Input power 1,8 kW
Conforms to the following European Directives:
2006/42/EC, 2006/95/EC, 2002/95/EC, 2002/96/EC, 2004/108/EC, 2000/14/EC
And are manufactured in accordance to the following standards or standardised
documents: EN 60335-1; EN 60335-2-79; EN 55014-1; EN 55014-2; EN 61000-3-2; EN 61000-
3-3; EN 61000-3-11; EN 60704-1
The Technical Documentation is kept by our authorised Representative in Europe who is:
Makita International Europe Ltd,
Michigan, Drive, Tongwell,
Milton Keynes, MK15 8JD, England
The conformity assessment procedure required by Directive 2000/14/EC was in
accordance with annex V
Measured Sound Power Level L
PA
: 83,1 dB (A); (K=3 dB(A)))
Guaranteed Sound Power Level L
WA
: 91 dB (A); (K=3 dB(A)))
06th December 2010
Mr Tomoyasu Kato
Director
Makita Corporation, 3-11-8 Sumiyoshi-Cho, Anjo, Aichi, 446-8502, Japan
Technical Data (EN) Unit
HW121
Output
L/min
6,5
Pressure
MPa
11
Maximum pressure
MPa
13
Power
kW
1,8
T° input
°C
50
Maximum input pressure
MPa
1
Repulsive force of the gun to the maximum pressure
N
14,95
Motor Insulation
-
Class F
Motor Protection
-
IPX5
Voltage
V/Hz
230/50
Sound level
K = 3 dB(A) :
L
PA
(EN 60704-1)
dB (A) 83,1
L
WA
(EN 60704-1)
dB (A) 91
Unit vibrations
K = 1,5
M/s
2
:
M/s
2
3,72
Weight
kg
17,8
90
