www.texas.dk
11
Storage
Store the trimmer dry and unavailable for children.
Maintance
Before any service and maintenance is done, the power must be disconnected!
Change the nylon line like this:
Turn the spool cover (1) counter clockwise to
unscrew it from the trimmerhead.
Rotate the spool (2) counter clockwise to
release the tabs (4) and lift the spool out of the
trimmerhead.
Take the inner spool out and rewind new line.
Make sure to follow the directions, indicated on
the spool. Make sure the spring (5) is in
position.
Press the line through the holes in the
trimmerhead (7).
Rotate the spool clockwise to secure the tabs in
the trimmerhead. Make sure the spring fits.
Fit the spool cover (1) and fasten it in a
clockwise direction to secure it to the
trimmerhead.
If you have any doubts, contact your dealer.
Specifications
Model ET 850-S
Connection 230 V / 50 Hz
Effect 850 Watt
RPM 7.500
Weight 4,5 kg
Cutting width 38 cm
Trimmerhead Tap’ n’ Go - 1,5 mm
