Connecting to Wireless Router

Remove the three antennas o the back of Router. (Here we take TL-WR941ND for example.)

TL-WR941ND

Notebook

Connect the TL-ANT2403N Antenna to Router with RP-SMA Connectors.

Unfold the TL-ANT2403N Antenna and x it on the provided chassis.

You are recommended to place the Antenna and the Router away from electrical devices, such as ceiling fans, home security systems,

microwave or the base for a cordless phone.
