- 43 -
3 Press 2 to select , and change the
size of the in-focus portion.
≥ Each time you press 2, the size of the in-focus
portion will change.
Medium size # Large size # Small size
≥ If you press 3/4, you can adjust the horizontal
position of the in-focus portion.
≥ If you press 1 and select [RESET], the in-focus portion will return to the default position, and will
also be resized to the medium size.
4 Press the ENTER button.
5 (When adjusting the brightness)
Press 2 to select , and adjust the
setting.
≥ Each time you press 2, the brightness setting will
change.
(Standard)
#
(Bright)
#
(Dark)
6 (When adjusting the vividness)
Press 1 to select , and adjust the setting.
≥ Each time you press 1, the vividness
setting
will change.
(Standard) # (Vivid) # (Most vivid)
7 Start recording.
≥ It will record with an interval. 1 second will be recorded for approximately every 6 seconds of
recording.
≥ To make the Miniature Effect easier to gain, record objects incorporating a distant view or those
that can provide depth or a skewed perspective. Also, use a tripod and avoid zooming.
≥ Audio cannot be recorded.
≥
You may see a lot of noise in the in-focus portion when recording dark subjects such as night scenes.
≥ [REC MODE] is set to [HA].
≥ The maximum recordable time is 12 hours.
≥ Motion pictures recorded with this function will look as if the frame rate is low.
1 (When adjusting the brightness)
Press 2 to select , and adjust the
setting.
≥ Each time you press 2, the brightness setting will
change.
(Standard)
#
(Bright)
#
(Dark)
2 (When adjusting the color balance)
Press 1 to select , and adjust the setting.
≥ Each time you press 1, the color balance
setting
will change.
(Blue) # (Red) # (Yellow)
3 Start recording.
≥ The sound is monaural.
[8mm movie]
ンユヴユヵンユヴユヵンユヴユヵ
3/3 3/3
ワユヹヵワユヹヵ
3/3
ワユヹヵ
MINI
8mm
3/3 3/3
ワユヹヵワユヹヵ
3/3
ワユヹヵ
8mm
