141
connection type specified in "Options". To disable this feature, click "Stop logging".
Online Users
The information of the on-line users connecting to the NAS by networking services is
shown on this page.
Tip:
Right click a log to disconnect the IP connection and block the IP.
Syslog C lient Managem ent
Syslog is a standard for forwarding the log messages on an IP network. Turn on this
option to save the event logs and connection logs to a remote Syslog server. When
converting the connection logs into a CSV file, the connection type and action will be
number coded. Please refer to the table below for the code meaning.
Connection type codes
Action codes
0 - UNKNOWN
1 - SAMBA
2 - FTP
3 - HTTP
4 - NFS
5 - AFP
6 - TELNET
7 - SSH
8 - ISCSI
0 - UNKNOWN
1 - DEL
2 - READ
3 - WRITE
4 - OPEN
5 - MKDIR
6 - NFSMOUNT_SUCC
7 - NFSMOUNT_FAIL
8 - RENAME
9 - LOGIN_FAIL
10 - LOGIN_SUCC
11 - LOGOUT
12 - NFSUMOUNT
13 - COPY
14 - MOVE
15 - ADD
Advanced Log Search
Advanced log search is provided to search for system event logs, system connection
logs and online users based on user preferences. First, specify the log type, users,
