75
With this function, RAID group capacity can be expanded by replacing hard disk drives
in an array one by one. This option is supported for the following RAID types: RAID 1,
RAID 5, RAID 6 and RAID 10. Follow the steps below to expand a RAID group:
1. Select a RAID group and click "Manage" > "Expand Capacity".
2. Select at least one hard disk drive. After the description displays "Please remove
this drive", remove the hard disk drive from the NAS or expansion enclosure.
3. After the description displays "You can replace this drive", plug in the new hard disk
drive to the drive slot. Repeat the same process for all hard drives to be replaced.
Click "Expand Capacity" to continue.
4. Click "Yes".
5. The chosen RAID group is expanded.
Note:
For details on RAID group management, please refer to Volumes .
Creating New Volum es for Storage Pools
To create a new volume for a storage pool, choose a storage pool first and click "New
Volume". Follow the onscreen instructions to finish the creation process. For step
details, please refer to the chapter on Volumes .
