77
2 TB
from 8 GB to 16 GB
4 TB
Above 16 GB
*For example, for 1 TB of SSD capacity, at least 4GB RAMs are required for the NAS.
On this page, users can choose to create, remove and expand a SSD volume and
configure the SSD cache.
Creating SSD Volum es
Follow the steps below to create a SSD volume:
1. Click "Create".
2. Select the SSD drive(s) and cache algorithm to create a SSD cache volume. Click
"Create".
3. Please note that all data on the selected hard drive(s) will be erased. Click "OK" if
you are certain about this.
4. An SSD cache volume is created.
Removing SSD Volum es
Follow the steps below to remove a SSD volume:
1. Click "Remove".
2. Please note that all data on the selected hard drive(s) will be erased. Click "Yes" if
you are certain about this.
3. The SSD volume is removed.
Expanding SSD Volum es
Follow the steps below to expand a SSD volume:
1. Click "Add SSD Drive".
2. Select the SSD drive(s) from the list and click "Expand".
3. Please note that all data on the selected hard drive(s) will be erased. Click "Yes" if
you are certain about this.
4. The SSD volume is expanded.
Configuring Volum es for SSD Cache
Follow the steps below to configure volumes for a SSD cache:
