 The appliance may be plugged in just the power net with ground connection. For your safety,

the ground connection must correspond with state rules and standards. Do not use non-

standard power supplies and connecting appliances.

 When plugging in, be sure, that the appliance is switched off.

 Do not use outdoors. Protect the unit from the extreme temperature, direct sunlight, sharp

corner shocks, moisture (never immerse into water). Don not touch with wet hands. In case

of contact with water immediately unplug it.

 In case of storing, cleaning or damaging please unplug the unit.

 If the power supply cord is damaged, it must be replaced by the manufacturer or its service

agent or a similarly qualified person in order to avoid a hazard.

 You should not repair the appliance by yourself. It must be done just by qualified specialists

of our service center.

 Only original spare parts may be used for repair.

 The heater is to be connected to a separate three-wire cable.

 The wires are to be connected according to the colors. It is necessary to assure the correct

and firm connection of yellow grounding wire. As the temperature of the supplying cable in

the entrance reaches more than 50˚С, heat-resistant cables are to be used.

 The unit is to be connected to a single wire power supply using a double pole automatic

switch rated for 25 А. The switch is to be set separately from the unit.

 A protective cutout device is to be installed to the power-supply circuit. Please contact

an authorized specialist.

 The grounding cable is to be connected directly to the ground of the customer’s grounding

source using a special separate cable.

II. Installation

The shower water heater is set on the wall at an altitude much greater than a person's height.

The water heater is completed with a bibb (tap-goose) and is fastened on the wall above the

sink. While using the water heater watch the water not to drop on it.

Installation arrangements are made on the account of the person who buys it.

The producer is not responsible for the defects caused by wrong setting or careless

usage of the following operating manual.

It is necessary to set up the water heater only by a specialist with necessary qualification.

A. Essential recommendations

1. The water heater should be set up by a qualified electrician.

2. On the electrical control panel must be set a special automatic device. To make the water heater

work it is necessary to have the water pressure -1/4 bar and the power of the water flow from 2

till 11 liters per minute. The given water heater can work at the minimum water pressure -1/4

bar and up to the maximum pressure -about 6 bars.

H. Heating element 5,5 kW

P. Power indicator

T. Thermostat (57

С)
