38
VQT3B75
Messages
The following messages or service numbers appear on the
television or unit’s display when something unusual is
detected during startup and use.
Cannot play.
¾
You inserted an incompatible disc.
Cannot play on this unit.
¾
You tried to play a non-compatible image.
¾
Confirm “SD” on the unit’s display is not displayed and
re-insert the card.
No disc is inserted.
¾
The disc may be upside down.
$ This operation is not available.
¾
Some operations are unsupported by the unit. For
example;
– BD-Video: During playback, reverse slow-motion or
reverse frame-by-frame is not possible.
IP address is not set.
¾
The “IP Address” in “IP Address / DNS Settings” is “---.
---. ---. ---”. Set the “IP Address”, “Subnet Mask”, and
“Gateway Address”. (Select the automatic address
acquisition if necessary.)
The wireless access point currently has a low
network security setting. It is recommended to
change to a higher setting.
¾
Authentication type for the Wireless LAN is set to “Open
system”, or the encryption type is set to “No encryption”.
It is recommended to encrypt for safety reasons. For
details, refer to the instructions of the Wireless router
being used. Encryption is required when playing back
video, etc., from DLNA compatible devices.
F99
¾
The unit fails to operate properly. Press [Í/I] on the
main unit for 3 seconds to switch the unit to standby,
then switch back on.
HDMI ONLY
¾
Some BD-Video discs can only be output with HDMI.
NET
¾
While connecting to a network.
No PLAY
¾
There is a viewing restriction on a BD-Video or
DVD-Video. (> 30)
No READ
¾
The media is dirty or badly scratched. The unit cannot
play.
PLEASE WAIT
¾
The unit is carrying out internal process. This is not a
malfunction. You cannot operate the unit while “PLEASE
WAIT” is displayed.
REMOVE
¾
The USB device is drawing too much power. Remove
the USB device.
SET
(“ ” stands for a number.)
¾
The remote control and main unit are using different
codes. Change the code on the remote control.
Press and hold [OK] and the
indicated number button at the
same time for more than 5 seconds.
U59
¾
The unit is hot.
The unit switches to standby for safety reasons. Wait for
about 30 minutes until the message disappears.
Select a position with good ventilation when installing the
unit. Do not block the ventilation hole on the side of the
unit.
H or F
(“ ” stands for a number.)
¾
There is something unusual.
¾
Check the unit using the troubleshooting guide. If the
service number does not disappear, do the following.
1 Disconnect the plug from the household mains socket
wait a few seconds, then reconnect it.
2 Press [Í/I] to turn the unit on. (The unit may be fixed.)
If the service number does not disappear despite doing the
above, request service from the dealer. Inform the dealer of
the service number when requesting service.
START
¾
The system is being restarted during the firmware
update. Please do not turn off the unit.
UPD/
(“ ” stands for a number.)
¾
The firmware is being updated.
Please do not turn off the unit.
FINISH
¾
The firmware update is complete.
On the television
On the unit’s display
DMP-BDT310_110EB-VQT3B75.book 38 ページ ２０１１年２月２１日 月曜日 午後５時１７分
