2
English
GB
FR DE ES IT NL PT DK SE FI NO RU PL CZ HU RO LV LT EE HR SI SK GR TR
compensate for and maintain desired RPM. Speed can be
set according to the sanding purpose or the surface of the
workpiece you will be using. Select clockwise to increase
speed for rough surfaces or for quick removal of stock and
anti-clockwise to decrease speed for the smaller, delicate
sanding applications.
ASSEMBLY
WARNING
The tool should never be connected to a power supply
when you are assembling parts, making adjustments,
cleaning, performing maintenance, or when the tool is
not in use. Disconnecting the tool will prevent accidental
starting that could cause serious injury.
SANDPAPER SELECTION
Selecting the correct size, grit and type of sand paper is
an extremely important step in achieving a high quality
sanded  nish. Aluminum oxide, silicon carbide, and
other synthetic abrasives are best for power sanding.
Natural abrasives, such as È int and garnet are too soft for
economical use in power sanding.
In general, coarse grit will remove the most material
and  ner grit will produce the best  nish in all sanding
operations. The condition of the surface to be sanded
will determine which grit will do the job. If the surface is
rough, start with a coarse grit and sand until the surface
is uniform. Medium grit may then be used to remove
scratches left by the coarser grit and  ner grit used for
 nishing of the surface. Always continue sanding with
each grit until surface is uniform.
WARNING
Do not use sander without sandpaper, doing so will
damage the cushion.
Sheet/pad recommended use
80-grit sanding sheet Coarse sanding
120-grit sanding sheet Light sanding
150-grit sanding sheet Light sanding
ATTACHING HOOK AND LOOP SANDING DISCS
See Figure 2.
1. Unplug the sander.
2. Align holes in hook and loop type sanding disc with
holes in pad, then carefully press fuzzy side of sanding
disc against pad as tightly as possible.
NOTE: It is recommended that you keep the sanding disc
backing pad clean to provide for best adhesion. Clean
occasionally by brushing lightly with a small brush.
ATTACHING THE DUST COLLECTION BOX
See Figure 3.
The dust collection box provides a dust collection system
for the sander. Sanding dust is drawn up through the holes
of the sanding disc and collected in the dust collection box
during sanding.
1. Unplug the sander.
2. Using a slight twisting motion, Â rmly slide the dust
collection box assembly in the blower exhaust on the
sander.
WARNING
Exercise caution when using this tool. Careless actions,
for even a fraction of a second, can result in serious
personal injury.
APPLICATIONS
You may use the sander for the purposes listed below:
Ê sanding on wood surfaces
Ê removing rust from and sanding steel surfaces
Ê polishing and scrubbing porcelain and metal
CAUTION
Keep the cord away from the sanding pad and position
the cord so that it will not be caught on lumber, tools, or
other objects during sanding.
WARNING
Always wear safety goggles or safety glasses with side
shields when operating this tool. Failure to do so could
result in dust, shavings, or loose particles being thrown
into your eyes, resulting in possible serious injury.
OPERATION
TURNING THE SANDER ON/OFF
See Figure 4.
À Turn on the sander: Push the on/off switch to the left.
À Turn off the sander: Push the on/off switch to the right.
OPERATING THE SANDER
See Figure 5.
1. Secure the workpiece to prevent it from moving under
the sander.
